Nichicon 10 μF Surface Mount Polymer Capacitor, 35 V dc
- RS Stock No.:
- 173-3288
- Mfr. Part No.:
- PCX1V100MCL1GS
- Brand:
- Nichicon
Subtotal (1 reel of 1000 units)*
£372.00
(exc. VAT)
£446.00
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 27 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 1000 + | £0.372 | £372.00 |
*price indicative
- RS Stock No.:
- 173-3288
- Mfr. Part No.:
- PCX1V100MCL1GS
- Brand:
- Nichicon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Nichicon | |
| Technology | Polymer, Electrolytic | |
| Product Type | Polymer Capacitor | |
| Capacitance | 10μF | |
| Voltage | 35 V dc | |
| Mount Type | Surface Mount | |
| Polarity | Polar | |
| Lead Pitch | 2.1mm | |
| Tolerance | ±20 % | |
| Maximum Operating Temperature | 125°C | |
| Dimensions | 6.3 (Dia) x 5.9 mm | |
| Length | 6mm | |
| Series | CX | |
| Height | 5.9mm | |
| Electrolyte Type | Solid | |
| Dissipation Factor | 12% | |
| Automotive Standard | No | |
| Lifetime | 3000 h | |
| Diameter | 6.3 mm | |
| Leakage Current | 70μA | |
| Minimum Operating Temperature | -55°C | |
| Ripple Current | 310mA | |
| Select all | ||
|---|---|---|
Brand Nichicon | ||
Technology Polymer, Electrolytic | ||
Product Type Polymer Capacitor | ||
Capacitance 10μF | ||
Voltage 35 V dc | ||
Mount Type Surface Mount | ||
Polarity Polar | ||
Lead Pitch 2.1mm | ||
Tolerance ±20 % | ||
Maximum Operating Temperature 125°C | ||
Dimensions 6.3 (Dia) x 5.9 mm | ||
Length 6mm | ||
Series CX | ||
Height 5.9mm | ||
Electrolyte Type Solid | ||
Dissipation Factor 12% | ||
Automotive Standard No | ||
Lifetime 3000 h | ||
Diameter 6.3 mm | ||
Leakage Current 70μA | ||
Minimum Operating Temperature -55°C | ||
Ripple Current 310mA | ||
- COO (Country of Origin):
- JP
CX Series
Nichicon CX Series Aluminium Electrolytic Capacitors are high reliability polymer capacitors which are rated up to 2000 hours. The CX series capacitors offer a high temperature range, high voltage, low ESR, and high ripple current. The CX series design makes them suitable for applications including motherboards and automobile infotainment systems.
High reliability
Low ESR
High ripple current
Long life up to 3000 hours
Lead free reflow soldering
