Wurth Elektronik 100μF Through Hole Polymer Capacitor, 16V dc
- RS Stock No.:
- 163-7189
- Mfr. Part No.:
- 870235373001
- Brand:
- Wurth Elektronik
Subtotal (1 box of 1500 units)*
£747.00
(exc. VAT)
£897.00
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 29 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Box* |
---|---|---|
1500 + | £0.498 | £747.00 |
*price indicative
- RS Stock No.:
- 163-7189
- Mfr. Part No.:
- 870235373001
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Wurth Elektronik | |
Technology | Polymer | |
Capacitance | 100µF | |
Dielectric Material Family | Aluminium | |
Voltage | 16V dc | |
Mounting Type | Through Hole | |
Equivalent Series Resistance | 12mΩ | |
Lead Pitch | 2.5mm | |
Tolerance | ±20% | |
Maximum Operating Temperature | +105°C | |
Height | 11mm | |
Dimensions | 6.3 (Dia) x 11mm | |
Series | WCAP-PT5H | |
Leakage Current | 160 μA | |
Diameter | 6.3mm | |
Dissipation Factor | 8% | |
Minimum Operating Temperature | -55°C | |
Ripple Current | 4.8A | |
Lifetime | 5000h | |
Select all | ||
---|---|---|
Brand Wurth Elektronik | ||
Technology Polymer | ||
Capacitance 100µF | ||
Dielectric Material Family Aluminium | ||
Voltage 16V dc | ||
Mounting Type Through Hole | ||
Equivalent Series Resistance 12mΩ | ||
Lead Pitch 2.5mm | ||
Tolerance ±20% | ||
Maximum Operating Temperature +105°C | ||
Height 11mm | ||
Dimensions 6.3 (Dia) x 11mm | ||
Series WCAP-PT5H | ||
Leakage Current 160 μA | ||
Diameter 6.3mm | ||
Dissipation Factor 8% | ||
Minimum Operating Temperature -55°C | ||
Ripple Current 4.8A | ||
Lifetime 5000h | ||
- COO (Country of Origin):
- CN
Wurth Elektronik General Purpose WCAP-PT5H Capacitor Series 105°C
Aluminium Polymer capacitors contain solid conductive polymer instead of wet electrolytic thus the benefits are:
High permissible ripple current due to lower ESR at high frequency range
Higher long term stability and expected life
No dry out phenomenon due to solid conductive polymer
High permissible ripple current due to lower ESR at high frequency range
Higher long term stability and expected life
No dry out phenomenon due to solid conductive polymer
Low ESR at high frequency range
Operating temperature: -55°C to +105°C
Long life product series with 5000h
Load life of 5000h @ +105°C
Wave soldering is recommended
Operating temperature: -55°C to +105°C
Long life product series with 5000h
Load life of 5000h @ +105°C
Wave soldering is recommended
Solid Radial 105°C
