Wurth Elektronik 33μF Through Hole Polymer Capacitor, 50V dc
- RS Stock No.:
- 163-7150
- Mfr. Part No.:
- 870055775003
- Brand:
- Wurth Elektronik
Subtotal (1 box of 600 units)*
£1,054.80
(exc. VAT)
£1,266.00
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 30 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Box* |
---|---|---|
600 + | £1.758 | £1,054.80 |
*price indicative
- RS Stock No.:
- 163-7150
- Mfr. Part No.:
- 870055775003
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Wurth Elektronik | |
Technology | Polymer | |
Capacitance | 33µF | |
Voltage | 50V dc | |
Dielectric Material Family | Aluminium | |
Mounting Type | Through Hole | |
Equivalent Series Resistance | 35mΩ | |
Lead Pitch | 5mm | |
Tolerance | ±20% | |
Length | 12.5mm | |
Maximum Operating Temperature | +105°C | |
Height | 12.5mm | |
Dimensions | 10 (Dia) x 12.5mm | |
Series | WCAP-PTHR | |
Dissipation Factor | 12% | |
Polarised | Polar | |
Minimum Operating Temperature | -55°C | |
Diameter | 10mm | |
Ripple Current | 2A | |
Lifetime | 2000h | |
Leakage Current | 330 μA | |
Select all | ||
---|---|---|
Brand Wurth Elektronik | ||
Technology Polymer | ||
Capacitance 33µF | ||
Voltage 50V dc | ||
Dielectric Material Family Aluminium | ||
Mounting Type Through Hole | ||
Equivalent Series Resistance 35mΩ | ||
Lead Pitch 5mm | ||
Tolerance ±20% | ||
Length 12.5mm | ||
Maximum Operating Temperature +105°C | ||
Height 12.5mm | ||
Dimensions 10 (Dia) x 12.5mm | ||
Series WCAP-PTHR | ||
Dissipation Factor 12% | ||
Polarised Polar | ||
Minimum Operating Temperature -55°C | ||
Diameter 10mm | ||
Ripple Current 2A | ||
Lifetime 2000h | ||
Leakage Current 330 μA | ||
- COO (Country of Origin):
- CN
Wurth Elektronik General Purpose WCAP-PTHR Capacitor Series 105°C
Aluminium Polymer capacitors contain solid conductive polymer instead of wet electrolytic thus the benefits are:
High permissible ripple current due to lower ESR at high frequency range
Higher long term stability and expected life
No dry out phenomenon due to solid conductive polymer
High permissible ripple current due to lower ESR at high frequency range
Higher long term stability and expected life
No dry out phenomenon due to solid conductive polymer
WCAP-PTHR is a high reliability polymer electrolytic capacitor series
Low ESR at high frequency range
High permissible ripple current
Load life of 2000h @ +105°C
Operating temperature: -55°C to +105°C
Wave soldering is recommended
Low ESR at high frequency range
High permissible ripple current
Load life of 2000h @ +105°C
Operating temperature: -55°C to +105°C
Wave soldering is recommended
Solid Radial 105°C
