Wurth Elektronik 820μF Through Hole Polymer Capacitor, 6.3V dc
- RS Stock No.:
- 163-7112
- Mfr. Part No.:
- 870025174009
- Brand:
- Wurth Elektronik
Bulk discount available
Subtotal (1 box of 800 units)*
£329.60
(exc. VAT)
£395.20
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 30 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Box* |
|---|---|---|
| 800 - 800 | £0.412 | £329.60 |
| 1600 - 2400 | £0.401 | £320.80 |
| 3200 - 4800 | £0.39 | £312.00 |
| 5600 - 9600 | £0.38 | £304.00 |
| 10400 + | £0.371 | £296.80 |
*price indicative
- RS Stock No.:
- 163-7112
- Mfr. Part No.:
- 870025174009
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Technology | Polymer | |
| Capacitance | 820µF | |
| Dielectric Material Family | Aluminium | |
| Voltage | 6.3V dc | |
| Mounting Type | Through Hole | |
| Equivalent Series Resistance | 12mΩ | |
| Lead Pitch | 3.5mm | |
| Tolerance | ±20% | |
| Maximum Operating Temperature | +105°C | |
| Height | 8mm | |
| Dimensions | 8 (Dia) x 8mm | |
| Series | WCAP-PTG5 | |
| Diameter | 8mm | |
| Lifetime | 2000h | |
| Minimum Operating Temperature | -55°C | |
| Leakage Current | 516.6 μA | |
| Ripple Current | 5.1A | |
| Dissipation Factor | 10% | |
Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Technology Polymer | ||
Capacitance 820µF | ||
Dielectric Material Family Aluminium | ||
Voltage 6.3V dc | ||
Mounting Type Through Hole | ||
Equivalent Series Resistance 12mΩ | ||
Lead Pitch 3.5mm | ||
Tolerance ±20% | ||
Maximum Operating Temperature +105°C | ||
Height 8mm | ||
Dimensions 8 (Dia) x 8mm | ||
Series WCAP-PTG5 | ||
Diameter 8mm | ||
Lifetime 2000h | ||
Minimum Operating Temperature -55°C | ||
Leakage Current 516.6 μA | ||
Ripple Current 5.1A | ||
Dissipation Factor 10% | ||
- COO (Country of Origin):
- CN
Wurth Elektronik General Purpose WCAP-PTG5 Capacitor Series 105°C
Aluminium Polymer capacitors contain solid conductive polymer instead of wet electrolytic thus the benefits are:
High permissible ripple current due to lower ESR at high frequency range
Higher long term stability and expected life
No dry out phenomenon due to solid conductive polymer
High permissible ripple current due to lower ESR at high frequency range
Higher long term stability and expected life
No dry out phenomenon due to solid conductive polymer
Features and Benefits
• Low ESR at high frequency range
• High permissible ripple current
• Load life of 2000 h @ +105°C
• Operating temperature: -55°C to +105°C
• Wave soldering is recommended
• High permissible ripple current
• Load life of 2000 h @ +105°C
• Operating temperature: -55°C to +105°C
• Wave soldering is recommended
Solid Radial 105°C
