KEMET 680μF Through Hole Polymer Capacitor, 6.3V dc
- RS Stock No.:
- 124-8260
- Mfr. Part No.:
- A750KK687M0JAAE016
- Brand:
- KEMET
Currently unavailable
Sorry, we don't know when this will be back in stock.
- RS Stock No.:
- 124-8260
- Mfr. Part No.:
- A750KK687M0JAAE016
- Brand:
- KEMET
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | KEMET | |
| Technology | Polymer | |
| Capacitance | 680µF | |
| Voltage | 6.3V dc | |
| Dielectric Material Family | Aluminium | |
| Mounting Type | Through Hole | |
| Equivalent Series Resistance | 16mΩ | |
| Lead Pitch | 3.5mm | |
| Tolerance | ±20% | |
| Depth | 8mm | |
| Maximum Operating Temperature | +105°C | |
| Height | 8mm | |
| Dimensions | 8 (Dia) x 8mm | |
| Series | A750 | |
| Electrolyte Type | Solid | |
| Dissipation Factor | 12% | |
| Lifetime | 2000h | |
| Leakage Current | 856.8 μA | |
| Polarised | Polar | |
| Diameter | 8mm | |
| Minimum Operating Temperature | -55°C | |
| Ripple Current | 4.1A | |
Select all | ||
|---|---|---|
Brand KEMET | ||
Technology Polymer | ||
Capacitance 680µF | ||
Voltage 6.3V dc | ||
Dielectric Material Family Aluminium | ||
Mounting Type Through Hole | ||
Equivalent Series Resistance 16mΩ | ||
Lead Pitch 3.5mm | ||
Tolerance ±20% | ||
Depth 8mm | ||
Maximum Operating Temperature +105°C | ||
Height 8mm | ||
Dimensions 8 (Dia) x 8mm | ||
Series A750 | ||
Electrolyte Type Solid | ||
Dissipation Factor 12% | ||
Lifetime 2000h | ||
Leakage Current 856.8 μA | ||
Polarised Polar | ||
Diameter 8mm | ||
Minimum Operating Temperature -55°C | ||
Ripple Current 4.1A | ||
