SMC 3/4 Pneumatic Solenoid Valve - Solenoid/Pilot SV1000 Series 24V dc

View all Pneumatic Solenoid Valves
Bulk discount available

Subtotal (1 unit)*

£98.87

(exc. VAT)

£118.64

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 2 unit(s) ready to ship
  • Plus 5 unit(s) ready to ship from another location
  • Plus 6 unit(s) shipping from 30 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 - 4£98.87
5 +£94.93

*price indicative

Pneumatic Solenoid Valves to Solenoid Valve Coils
Need Coils for Your Solenoid Valves?
Pneumatic solenoid valves rely on compatible coils to operate efficiently. If you're browsing valves, don’t forget to check out our range of solenoid valve coils—designed to deliver reliable actuation and optimal performance. Whether you're replacing a coil or building a new system, pairing your valve with the right coil ensures smooth and responsive control.
Shop Now
RS Stock No.:
838-8639
Mfr. Part No.:
SV1A00-5FUD
Brand:
SMC
Find similar products by selecting one or more attributes.
Select all

Brand

SMC

Function

3/4

Actuation Type

Solenoid/Pilot

Manufacturer Series

SV1000

Mounting Style

Manifold

Solenoid Voltage

24V dc

Solenoid Fitted

Yes

Body Material

Die Cast Aluminium

Solenoid Power Consumption

0.6W

Minimum Operating Pressure

0.15MPa

Minimum Operating Temperature

-10°C

Maximum Operating Pressure

0.7 MPa

Maximum Operating Temperature

+50°C

Non Compliant

COO (Country of Origin):
JP

SV Series Solenoid Valves


The SV Series had been designed to make instillation and changes simpler by utilising a multi-connector rather than the conventional lead wires for internal manifold wiring. Cassette base type manifolds offer great flexibility and modified sections can be added using a simple release mechanism. For ultimate flexibility conventional tie-rod base manifolds are also available. The use of 34 pin connectors allows up to 16 stations with double solenoids.

Fluid: air
Operating pressure range: -100kPa to 0.7MPa
Response time (at 0.5MPa): 18ms or less
Coil rated voltage: 12, 24 Vdc
Ambient and fluid temperature: -10 to +50 °C
Enclosure: IP67 (based on IEC529)


SMC SV Series
