SMC 5/2 Pneumatic Solenoid Valve - Pilot/Pilot Rc 1/8 SYJA7000 Series
- RS Stock No.:
- 715-0812
- Mfr. Part No.:
- SYJA7120-01
- Brand:
- SMC
Bulk discount available
Subtotal (1 unit)*
£74.97
(exc. VAT)
£89.96
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 23 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 4 | £74.97 |
5 + | £70.56 |
*price indicative
- RS Stock No.:
- 715-0812
- Mfr. Part No.:
- SYJA7120-01
- Brand:
- SMC
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | SMC | |
Function | 5/2 | |
Connection Port Thread | Rc 1/8 | |
Actuation Type | Pilot/Pilot | |
Manufacturer Series | SYJA7000 | |
Mounting Style | Stand-Alone | |
Number of Ports | 5/2 | |
Body Material | Die Cast Aluminium | |
Maximum Flow Rate | 626L/min | |
Minimum Operating Pressure | 0.15MPa | |
Thread Size | 1/8in | |
Maximum Operating Pressure | 0.7 MPa | |
Maximum Operating Temperature | +50°C | |
Minimum Operating Temperature | -10°C | |
Thread Standard | Rc | |
Select all | ||
---|---|---|
Brand SMC | ||
Function 5/2 | ||
Connection Port Thread Rc 1/8 | ||
Actuation Type Pilot/Pilot | ||
Manufacturer Series SYJA7000 | ||
Mounting Style Stand-Alone | ||
Number of Ports 5/2 | ||
Body Material Die Cast Aluminium | ||
Maximum Flow Rate 626L/min | ||
Minimum Operating Pressure 0.15MPa | ||
Thread Size 1/8in | ||
Maximum Operating Pressure 0.7 MPa | ||
Maximum Operating Temperature +50°C | ||
Minimum Operating Temperature -10°C | ||
Thread Standard Rc | ||
- COO (Country of Origin):
- JP
G 1/ 8 SYJ700/7000 Valves
The SYJ series of valves have low power consumption and therefore decreased engineering costs. Their space saving design means that the SYJ valves can be individually mounted onto sub plates or configured onto base mounted manifolds. These SYJ700 & 7000 valves have a pilot exhaust and have a copper free design.
110V & 220V valves supplied with DIN connector
Copper free design
Low power consumption
Space efficient
Copper free design
Low power consumption
Space efficient
Note
24V valves require L Type connector plug 234-5743
SMC SYJ & VF Series
Low power consumption enables direct operation by PLC. They have a non locking manual override. Operating temperature: -10 to +50°C.
