SMC Rc 1/8 Pneumatic Regulator - 1 Mpa, AR20K-01BG-B 20 L/min AR
- RS Stock No.:
- 395-307
- Mfr. Part No.:
- AR20K-01BG-B
- Brand:
- SMC
Subtotal (1 unit)*
£30.73
(exc. VAT)
£36.88
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 10 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £30.73 |
*price indicative
- RS Stock No.:
- 395-307
- Mfr. Part No.:
- AR20K-01BG-B
- Brand:
- SMC
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SMC | |
| Product Type | Pneumatic Regulator | |
| Port Size | Rc 1/8 | |
| Series | AR | |
| Body Material | Die Cast Zinc | |
| Maximum Flow Rate | 20L/min | |
| Maximum Operating Pressure | 1 Mpa | |
| Minimum Operating Temperature | -5°C | |
| Maximum Operating Temperature | 60°C | |
| Standards/Approvals | RoHS | |
| Pressure Setting Range | 0.05 to 0.4 MPa | |
| Select all | ||
|---|---|---|
Brand SMC | ||
Product Type Pneumatic Regulator | ||
Port Size Rc 1/8 | ||
Series AR | ||
Body Material Die Cast Zinc | ||
Maximum Flow Rate 20L/min | ||
Maximum Operating Pressure 1 Mpa | ||
Minimum Operating Temperature -5°C | ||
Maximum Operating Temperature 60°C | ||
Standards/Approvals RoHS | ||
Pressure Setting Range 0.05 to 0.4 MPa | ||
- COO (Country of Origin):
- CN
The SMC Modular type regulator designed for precise pressure control in pneumatic systems. It is compact and versatile, making it suitable for various industrial applications.
Built in backflow mechanism for efficient operation
Optional embedded pressure gauge for enhanced functionality
