CEJN Brass, Stainless Steel Male Pneumatic Quick Connect Coupling, 13mm Hose Barb
- RS Stock No.:
- 121-8035
- Mfr. Part No.:
- C103152005
- Brand:
- CEJN
Subtotal (1 unit)*
£34.18
(exc. VAT)
£41.02
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 26 unit(s) shipping from 27 October 2025
- Plus 4 unit(s) shipping from 27 October 2025
- Plus 999,999,973 unit(s) shipping from 01 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £34.18 |
*price indicative
- RS Stock No.:
- 121-8035
- Mfr. Part No.:
- C103152005
- Brand:
- CEJN
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | CEJN | |
| Coupling Gender | Male | |
| Manufacturer Series | 315 eSafe | |
| Connection Type | Hose Barb | |
| Hose Barb Connection | 13mm | |
| Material | Brass, Stainless Steel | |
| Maximum Operating Pressure | 16bar | |
| Finish | Zinc Plated | |
| Minimum Operating Temperature | -20°C | |
| Seal Material | NBR | |
| Maximum Operating Temperature | +100°C | |
Select all | ||
|---|---|---|
Brand CEJN | ||
Coupling Gender Male | ||
Manufacturer Series 315 eSafe | ||
Connection Type Hose Barb | ||
Hose Barb Connection 13mm | ||
Material Brass, Stainless Steel | ||
Maximum Operating Pressure 16bar | ||
Finish Zinc Plated | ||
Minimum Operating Temperature -20°C | ||
Seal Material NBR | ||
Maximum Operating Temperature +100°C | ||
- COO (Country of Origin):
- SE
CEJN eSafe 315 Series
CEJN’s eSafe pneumatic couplings combine high performance and ease of use in a compact and robust design. The easy to use two stage disconnection vents pressure before disconnection, reducing noise and the risk of injury from hose whip and can be operated with using one hand.
The high flow capacity and a minimal pressure drop of the eSafe quick connect couplings help reduce losses and increased productivity and efficiency.
The high flow capacity and a minimal pressure drop of the eSafe quick connect couplings help reduce losses and increased productivity and efficiency.
Features and Benefits
Complies with ISO 4414 and EN 983
86N Connection force
7.5mm nominal flow diameter
1950 l/min flow rate
Asian Standard Compatible
86N Connection force
7.5mm nominal flow diameter
1950 l/min flow rate
Asian Standard Compatible
Applications
CEJN's eSafe coulings are suitable for use in a vast range or workplaces using compressed air including
carpentry, the manufacturing industry, automotive repair shops and mining
carpentry, the manufacturing industry, automotive repair shops and mining
