SMC KC Series Straight Tube-to-Tube Adaptor, Push In 8 mm to Push In 8 mm, Tube-to-Tube Connection Style
- RS Stock No.:
- 435-5758
- Mfr. Part No.:
- KCH08-00
- Brand:
- SMC
Image representative of range
Bulk discount available
Subtotal (1 unit)*
£8.56
(exc. VAT)
£10.27
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 1 unit(s) shipping from 13 October 2025
- Plus 6 unit(s) shipping from 13 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £8.56 |
| 5 - 9 | £8.05 |
| 10 + | £7.72 |
*price indicative
- RS Stock No.:
- 435-5758
- Mfr. Part No.:
- KCH08-00
- Brand:
- SMC
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SMC | |
| Connector A | Push In 8 mm | |
| Connector B | Push In 8 mm | |
| Pneumatic Fitting Type | Straight Tube-to-Tube Adaptor | |
| Connection Style | Tube-to-Tube | |
| Manufacturer Series | KC | |
| Finish | Nickel Plated | |
| Maximum Operating Temperature | +60°C | |
| Minimum Operating Temperature | -5°C | |
| Body Material | PBT | |
| Maximum Operating Pressure | 1 MPa | |
Select all | ||
|---|---|---|
Brand SMC | ||
Connector A Push In 8 mm | ||
Connector B Push In 8 mm | ||
Pneumatic Fitting Type Straight Tube-to-Tube Adaptor | ||
Connection Style Tube-to-Tube | ||
Manufacturer Series KC | ||
Finish Nickel Plated | ||
Maximum Operating Temperature +60°C | ||
Minimum Operating Temperature -5°C | ||
Body Material PBT | ||
Maximum Operating Pressure 1 MPa | ||
Non Compliant
- COO (Country of Origin):
- JP
Self Seal Connector
The KC series from SMC are one touch fittings with built-in self-seal mechanism to prevent air exhaust when removing tubing.
Electro less nickel plated for copper-free applications.
Effective when piping in a confined space.
Effective when piping in a confined space.
