Festo MS series 0.01 μm 1/2 in G 12 bar Pneumatic Filter 900 L/min max with Automatic drain

RS Stock No.:: 202-3402
Mfr. Part No.:: MS6-LFM-1/2-ARV-DA
Brand:: Festo

Festo MS series 0.01 μm 1/2 in G 12 bar Pneumatic Filter 900 L/min max with Automatic drain

Subtotal (1 unit)*

£149.93

(exc. VAT)

£179.92

(inc. VAT)

FREE delivery for orders over £50.00

In Stock

1 unit(s) ready to ship from another location

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 +	£149.93

*price indicative

MS-Series Products

Discover Festo's innovative MS-Series range of products, designed for optimal performance in automation. Enhance your industrial processes today.

Browse the range

RS Stock No.:: 202-3402
Mfr. Part No.:: MS6-LFM-1/2-ARV-DA
Brand:: Festo

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Festo
	Filtration Size	0.01μm
	Product Type	Pneumatic Filter
	Port Size	1/2 in G
	Drain Type	Automatic
	Series	MS
	Seal Material	Nitrile Rubber (NBR)
	Maximum Flow Rate	900L/min
	Maximum Operating Pressure	12 bar
	Minimum Operating Temperature	5°C
	Maximum Operating Temperature	60°C
	Standards/Approvals	RoHS, ISO8573-1:2010 (6:8:4), ISO8573-1:2010 (1:7:2)
	Bowl Material	Plastic

	Select all
	Brand Festo
	Filtration Size 0.01μm
	Product Type Pneumatic Filter
	Port Size 1/2 in G
	Drain Type Automatic
	Series MS
	Seal Material Nitrile Rubber (NBR)
	Maximum Flow Rate 900L/min
	Maximum Operating Pressure 12 bar
	Minimum Operating Temperature 5°C
	Maximum Operating Temperature 60°C
	Standards/Approvals RoHS, ISO8573-1:2010 (6:8:4), ISO8573-1:2010 (1:7:2)
	Bowl Material Plastic

COO (Country of Origin):: HU

Festo MS Pneumatic Filter, 1/2 inches Port Size, 0.01 μm Filtration Size - MS6-LFM-1/2-ARV-DA, Numeric Part Number:536877

This pneumatic filter conditions compressed Air for industrial control and automation systems by removing fine particulates and managing condensate disposal. It is designed for installation in pneumatic supply lines where controlled filtration and efficient fluid removal are required, operating across a typical industrial temperature range and compatible with standard G-thread connections.

Features and Benefits:

• 0.01μm Fibre filtration protects sensitive valves and actuators
• 900 L/min maximum flow supports moderate-duty process lines
• 12 bar maximum pressure enables higher-pressure applications
• Automatic drain reduces manual maintenance interventions
• Manual drain option allows controlled servicing when required
• Polycarbonate bowl provides clear Visual condensate inspection

Applications

• Suitable for factory automation pneumatic control cabinets
• Ideal for instrumentation Air supply to pneumatic valves
• Used with Air preparation units in assembly robots
• Can be used for compressed Air conditioning in test rigs
• Used for general-purpose plant Air in mechanical workshops

What materials contact the compressed Air that could affect compatibility?

Seals are MADE from NBR and the bowl is polycarbonate, both selected for common industrial media compatibility and Visual condensate monitoring.

How does the filtration grade relate to downstream component protection?

The 0.01μm Fibre element captures very fine particles and aerosols, reducing wear in precision actuators and preventing contamination of sensitive electrical and pneumatic instruments.

What connection and installation considerations apply to piping?

The unit uses a G-thread port sized at 1/2 in for straightforward integration with standard BSPP pneumatic fittings.

What are the operating temperature limits for stable performance?

The filter is specified for use between -10°C and 60°C to suit typical plant environments and to prevent material stress outside this range.
