SMC SFD series 0.01 μm Push In 8 mm 10 bar Pneumatic Filter 500 L/min max
- RS Stock No.:
- 398-295
- Mfr. Part No.:
- SFD200-C08
- Brand:
- SMC
Subtotal (1 unit)*
£199.54
(exc. VAT)
£239.45
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 11 unit(s) shipping from 04 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £199.54 |
*price indicative
- RS Stock No.:
- 398-295
- Mfr. Part No.:
- SFD200-C08
- Brand:
- SMC
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SMC | |
| Product Type | Pneumatic Filter | |
| Filtration Size | 0.01μm | |
| Port Size | Push In 8 mm | |
| Series | SFD | |
| Seal Material | Fluorelastomer | |
| Maximum Flow Rate | 500L/min | |
| Maximum Operating Pressure | 10 bar | |
| Maximum Operating Temperature | 45°C | |
| Standards/Approvals | ISO14644-1, IEC 60204-1, ISO 10218-1, ISO 4414, RoHS, ISO 4413 | |
| Filter Type | Air | |
| Bowl Material | Resin | |
| Select all | ||
|---|---|---|
Brand SMC | ||
Product Type Pneumatic Filter | ||
Filtration Size 0.01μm | ||
Port Size Push In 8 mm | ||
Series SFD | ||
Seal Material Fluorelastomer | ||
Maximum Flow Rate 500L/min | ||
Maximum Operating Pressure 10 bar | ||
Maximum Operating Temperature 45°C | ||
Standards/Approvals ISO14644-1, IEC 60204-1, ISO 10218-1, ISO 4414, RoHS, ISO 4413 | ||
Filter Type Air | ||
Bowl Material Resin | ||
The SMC Clean Air Filter is equipped with a built-in hollow fibre membrane designed to provide highly effective filtration. With a nominal filtration rate of 0.01 μm, this filter ensures the removal of fine contaminants, offering superior protection for sensitive equipment and systems.
Efficient filteration
Effectively removing fine particles and contaminants
