SKF SYF 50 FM Plummer Block House -, 50 mm ID
- RS Stock No.:
- 463-437
- Mfr. Part No.:
- SYF 50 FM
- Brand:
- SKF
Subtotal (1 unit)*
£130.45
(exc. VAT)
£156.54
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 04 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £130.45 |
*price indicative
- RS Stock No.:
- 463-437
- Mfr. Part No.:
- SYF 50 FM
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Plummer Block House | |
| Inside Diameter | 50mm | |
| Material | Cast Iron | |
| Centre Height | 57.2mm | |
| Static Load Rating | 23.2kN | |
| Mount Hole Size | M16 | |
| Locking Type | Eccentric Locking Collar | |
| Length | 135mm | |
| Depth | 43.7mm | |
| Dynamic Load Rating | 35.1kN | |
| Number of Bolts | 2 | |
| Bore Type | Cylindrical | |
| Standards/Approvals | RoHS | |
| Height | 114mm | |
| Series | SYF 50 FM | |
| Limiting Speed | 4000rpm | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Plummer Block House | ||
Inside Diameter 50mm | ||
Material Cast Iron | ||
Centre Height 57.2mm | ||
Static Load Rating 23.2kN | ||
Mount Hole Size M16 | ||
Locking Type Eccentric Locking Collar | ||
Length 135mm | ||
Depth 43.7mm | ||
Dynamic Load Rating 35.1kN | ||
Number of Bolts 2 | ||
Bore Type Cylindrical | ||
Standards/Approvals RoHS | ||
Height 114mm | ||
Series SYF 50 FM | ||
Limiting Speed 4000rpm | ||
The SKF Short base pillow block ball bearing units consist of an insert bearing mounted in a cast iron housing that can be bolted to a support surface. This variant is intended for use in applications where the direction of rotation is constant. It has a narrow inner ring and is locked onto the shaft by an eccentric locking collar, making it easy to mount.
Strong
Narrow design
Ready to mount
Lubricated and sealed bearing
Designed for rotation in one direction
Accommodate static initial misalignment
