SKF SY 30 TR Plummer Block House -, 30 mm ID
- RS Stock No.:
- 463-354
- Mfr. Part No.:
- SY 30 TR
- Brand:
- SKF
Subtotal (1 unit)*
£58.04
(exc. VAT)
£69.65
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit |
|---|---|
| 1 + | £58.04 |
*price indicative
- RS Stock No.:
- 463-354
- Mfr. Part No.:
- SY 30 TR
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Inside Diameter | 30mm | |
| Product Type | Plummer Block House | |
| Material | Cast Iron | |
| Static Load Rating | 11.2kN | |
| Centre Height | 42.9mm | |
| Locking Type | Eccentric Locking Collar | |
| Mount Hole Size | 12 mm | |
| Length | 152mm | |
| Dynamic Load Rating | 19.5kN | |
| Depth | 40mm | |
| Number of Bolts | 2 | |
| Bore Type | Cylindrical | |
| Height | 82mm | |
| Series | SY 30 TR | |
| Standards/Approvals | RoHS | |
| Limiting Speed | 3800rpm | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Inside Diameter 30mm | ||
Product Type Plummer Block House | ||
Material Cast Iron | ||
Static Load Rating 11.2kN | ||
Centre Height 42.9mm | ||
Locking Type Eccentric Locking Collar | ||
Mount Hole Size 12 mm | ||
Length 152mm | ||
Dynamic Load Rating 19.5kN | ||
Depth 40mm | ||
Number of Bolts 2 | ||
Bore Type Cylindrical | ||
Height 82mm | ||
Series SY 30 TR | ||
Standards/Approvals RoHS | ||
Limiting Speed 3800rpm | ||
The SKF Pillow block ball bearing units consist of an insert bearing mounted in a cast iron housing that can be bolted to a support surface. It is suitable for applications with both constant and alternating directions of rotation. It has an inner ring extended on both sides and is locked onto the shaft by tightening a set screw on the inner ring, making it easy to mount.
Strong
Ready to mount
Lubricated and sealed bearing
Quick locking onto the shaft
Cost effective
