Phoenix Contact 3.81mm Pitch 20 Way Right Angle Pluggable Terminal Block, Header, Through Hole, Solder Termination
- RS Stock No.:
- 882-0925
- Mfr. Part No.:
- 1848449
- Brand:
- Phoenix Contact
Available to back order for despatch 23/08/2024
Price Each (In a Box of 50)
£6.677
(exc. VAT)
£8.012
(inc. VAT)
Units | Per unit | Per Box* |
---|---|---|
50 + | £6.677 | £333.85 |
*price indicative
- RS Stock No.:
- 882-0925
- Mfr. Part No.:
- 1848449
- Brand:
- Phoenix Contact
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- DE
Product Details
PCB headers, nominal cross section: 1.5 mm², color: green, nominal current: 8 A, rated voltage (III/2): 160 V, contact surface: Tin, type of contact: Male connector, Number of potentials: 20, Number of rows: 1, Number of positions per row: 20, number of connections: 20, product range: MC 1,5/..-GF, pitch: 3.81 mm, mounting: Wave soldering, pin layout: Linear pinning, solder pin [P]: 3.4 mm, Stecksystem: MINI COMBICON, Locking: Screw locking, type of packaging: packed in cardboard
Specifications
Attribute | Value |
---|---|
Pluggable Terminal Block Type | Header |
Number of Contacts | 20 |
Pitch | 3.81mm |
Series | MC 1.5/20-GF-3.81 |
Number of Rows | 1 |
Body Orientation | Right Angle |
Mounting Type | Through Hole |
Termination Method | Solder |
Current Rating | 8.0A |
Voltage Rating | 250.0 V |
