Phoenix Contact 7.62mm Pitch 4 Way Pluggable Terminal Block, Inverted Plug, Cable Mount, Spring Cage Termination
- RS Stock No.:
- 853-5624
- Mfr. Part No.:
- 1748888
- Brand:
- Phoenix Contact
Available to back order for despatch 27/09/2024
Price Each (In a Box of 50)
£4.985
(exc. VAT)
£5.982
(inc. VAT)
Units | Per unit | Per Box* |
|---|---|---|
| 50 + | £4.985 | £249.25 |
*price indicative
- RS Stock No.:
- 853-5624
- Mfr. Part No.:
- 1748888
- Brand:
- Phoenix Contact
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- BG
Product Details
PCB connector, nominal cross section: 6 mm², color: green, nominal current: 41 A, rated voltage (III/2): 1000 V, contact surface: Tin, type of contact: Male connector, Number of potentials: 4, Number of rows: 1, Number of positions per row: 4, number of connections: 4, product range: ISPC 5/..-STGCL, pitch: 7.62 mm, connection method: Push-in spring connection, conductor/PCB connection direction: 0 °, Stecksystem: POWER COMBICON 5, Locking: Clip locking, type of packaging: packed in cardboard
Specifications
Attribute | Value |
|---|---|
| Pluggable Terminal Block Type | Inverted Plug |
| Number of Contacts | 4 |
| Pitch | 7.62mm |
| Series | ISPC 5/ 4-STGCL-7.62 |
| Number of Rows | 1 |
| Body Orientation | Straight |
| Mounting Type | Cable Mount |
| Termination Method | Spring Cage |
| Current Rating | 41A |
| Voltage Rating | 1 kV |
| Colour | Green |
| Material | Polyamide, Tin |
