Phoenix Contact COMBICON MCV Series Pluggable Terminal Block, 4-Contact, 3.5 mm Pitch, 1 Row, 1731497
- RS Stock No.:
- 853-5267
- Mfr. Part No.:
- 1731497
- Brand:
- Phoenix Contact
Subtotal (1 box of 50 units)*
£56.35
(exc. VAT)
£67.60
(inc. VAT)
FREE delivery for orders over £50.00
Stocked by manufacturer
- Ready to ship from 24 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Box* |
|---|---|---|
| 50 + | £1.127 | £56.35 |
*price indicative
- RS Stock No.:
- 853-5267
- Mfr. Part No.:
- 1731497
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Number of Contacts | 4 | |
| Product Type | Pluggable Terminal Block | |
| Pitch | 3.5mm | |
| Current | 8A | |
| Number of Rows | 1 | |
| Housing Material | Polybutylene Terephthalate | |
| Connector Gender | Female | |
| Orientation | Straight | |
| Colour | Green | |
| Wire Connection Method | Solder | |
| Voltage | 250 V | |
| Width | 17.6 mm | |
| Length | 7.25mm | |
| Depth | 12.6mm | |
| Standards/Approvals | EU RoHS, CHINA RoHS, CSA, cULus, EU REACH SVHC | |
| Series | COMBICON MCV | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Number of Contacts 4 | ||
Product Type Pluggable Terminal Block | ||
Pitch 3.5mm | ||
Current 8A | ||
Number of Rows 1 | ||
Housing Material Polybutylene Terephthalate | ||
Connector Gender Female | ||
Orientation Straight | ||
Colour Green | ||
Wire Connection Method Solder | ||
Voltage 250 V | ||
Width 17.6 mm | ||
Length 7.25mm | ||
Depth 12.6mm | ||
Standards/Approvals EU RoHS, CHINA RoHS, CSA, cULus, EU REACH SVHC | ||
Series COMBICON MCV | ||
- COO (Country of Origin):
- DE
