PTR HARTMANN AKZS Series Pluggable Terminal Block, 6-Contact, 5.08 mm Pitch, 1 Row, AKZS 6
- RS Stock No.:
- 285-7169
- Distrelec Article No.:
- 148-41-501
- Mfr. Part No.:
- AKZS 6
- Brand:
- PTR HARTMANN
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 285-7169
- Distrelec Article No.:
- 148-41-501
- Mfr. Part No.:
- AKZS 6
- Brand:
- PTR HARTMANN
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | PTR HARTMANN | |
| Number of Contacts | 6 | |
| Product Type | Pluggable Terminal Block | |
| Pitch | 5.08mm | |
| Number of Rows | 1 | |
| Current | 15A | |
| Housing Material | Polyamide | |
| Minimum Wire Size mm² | 0.2mm² | |
| Maximum Wire Size mm² | 4mm² | |
| Minimum Wire Size AWG | 28AWG | |
| Maximum Wire Size AWG | 12AWG | |
| Orientation | Straight | |
| Colour | Green | |
| Wire Connection Method | Screw | |
| Voltage | 300V | |
| Standards/Approvals | VDE | |
| Series | AKZS | |
| Select all | ||
|---|---|---|
Brand PTR HARTMANN | ||
Number of Contacts 6 | ||
Product Type Pluggable Terminal Block | ||
Pitch 5.08mm | ||
Number of Rows 1 | ||
Current 15A | ||
Housing Material Polyamide | ||
Minimum Wire Size mm² 0.2mm² | ||
Maximum Wire Size mm² 4mm² | ||
Minimum Wire Size AWG 28AWG | ||
Maximum Wire Size AWG 12AWG | ||
Orientation Straight | ||
Colour Green | ||
Wire Connection Method Screw | ||
Voltage 300V | ||
Standards/Approvals VDE | ||
Series AKZS | ||
- COO (Country of Origin):
- DE
The versatile and high-quality terminal block suitable for a wide range of applications. With its solid construction and excellent performance, it is a reliable choice for various electrical projects.
Designed for wire sizes ranging from 0.2 mm² to 2.5 mm², offering flexibility in installation
Operating temperature range of -30 °C to 105 °C, ensuring reliable performance in different environments
Suitable for solid and stranded wire types, making it ideal for various wiring configurations
Flame-retardant PA 6.6 insulating material for enhanced safety
Rated voltage of 300 V and rated current of 15 A, meeting industry standards for electrical equipment
