PTR HARTMANN AK1550 Series Pluggable Terminal Block, 12-Contact, 3.5 mm Pitch, 1 Row, AK1550/12-3.5
- RS Stock No.:
- 285-7163
- Distrelec Article No.:
- 148-41-207
- Mfr. Part No.:
- AK1550/12-3.5
- Brand:
- PTR HARTMANN
Subtotal (1 unit)*
£6.02
(exc. VAT)
£7.22
(inc. VAT)
FREE delivery for orders over £60.00
Being discontinued
- Final 52 unit(s), ready to ship from another location
Units | Per unit |
|---|---|
| 1 + | £6.02 |
*price indicative
- RS Stock No.:
- 285-7163
- Distrelec Article No.:
- 148-41-207
- Mfr. Part No.:
- AK1550/12-3.5
- Brand:
- PTR HARTMANN
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | PTR HARTMANN | |
| Product Type | Pluggable Terminal Block | |
| Number of Contacts | 12 | |
| Pitch | 3.5mm | |
| Current | 8A | |
| Number of Rows | 1 | |
| Housing Material | Polyamide | |
| Minimum Wire Size mm² | 0.14mm² | |
| Maximum Wire Size mm² | 1.5mm² | |
| Minimum Wire Size AWG | 28AWG | |
| Maximum Wire Size AWG | 16AWG | |
| Orientation | Straight | |
| Colour | Green | |
| Voltage | 300V | |
| Width | 42mm | |
| Series | AK1550 | |
| Standards/Approvals | VDE | |
| Select all | ||
|---|---|---|
Brand PTR HARTMANN | ||
Product Type Pluggable Terminal Block | ||
Number of Contacts 12 | ||
Pitch 3.5mm | ||
Current 8A | ||
Number of Rows 1 | ||
Housing Material Polyamide | ||
Minimum Wire Size mm² 0.14mm² | ||
Maximum Wire Size mm² 1.5mm² | ||
Minimum Wire Size AWG 28AWG | ||
Maximum Wire Size AWG 16AWG | ||
Orientation Straight | ||
Colour Green | ||
Voltage 300V | ||
Width 42mm | ||
Series AK1550 | ||
Standards/Approvals VDE | ||
- COO (Country of Origin):
- DE
The Straight Female header with 3.5mm Pitch. It has 12 pole and Combustibility Class of UL 94 V-0.
VDE approved
cURus approved
