Phoenix Contact MCC 1/-STZ Series Pluggable Terminal Block, 6-Contact, 3.81 mm Pitch, 1 Row, 1852215
- RS Stock No.:
- 265-7444
- Mfr. Part No.:
- 1852215
- Brand:
- Phoenix Contact
Subtotal (1 pack of 50 units)*
£61.70
(exc. VAT)
£74.05
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 21 October 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 50 + | £1.234 | £61.70 |
*price indicative
- RS Stock No.:
- 265-7444
- Mfr. Part No.:
- 1852215
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Product Type | Pluggable Terminal Block | |
| Number of Contacts | 6 | |
| Pitch | 3.81mm | |
| Current | 8A | |
| Number of Rows | 1 | |
| Housing Material | Polyamide | |
| Minimum Wire Size mm² | 2mm² | |
| Maximum Wire Size mm² | 1mm² | |
| Connector Gender | Female | |
| Minimum Wire Size AWG | 24AWG | |
| Maximum Wire Size AWG | 18AWG | |
| Orientation | 0° | |
| Wire Connection Method | Crimp | |
| Colour | Green | |
| Voltage | 160V | |
| Depth | 8.7mm | |
| Length | 23.1mm | |
| Standards/Approvals | cULus Recognised, EAC | |
| Width | 23.65mm | |
| Series | MCC 1/-STZ | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Product Type Pluggable Terminal Block | ||
Number of Contacts 6 | ||
Pitch 3.81mm | ||
Current 8A | ||
Number of Rows 1 | ||
Housing Material Polyamide | ||
Minimum Wire Size mm² 2mm² | ||
Maximum Wire Size mm² 1mm² | ||
Connector Gender Female | ||
Minimum Wire Size AWG 24AWG | ||
Maximum Wire Size AWG 18AWG | ||
Orientation 0° | ||
Wire Connection Method Crimp | ||
Colour Green | ||
Voltage 160V | ||
Depth 8.7mm | ||
Length 23.1mm | ||
Standards/Approvals cULus Recognised, EAC | ||
Width 23.65mm | ||
Series MCC 1/-STZ | ||
- COO (Country of Origin):
- PL
The Phoenix Contact PCB connector has tin contact surface and crimp connection, inexpensive connection of large quantities of pre-assembled conductors with green color.
Female connector
Copper alloy contact material
