Phoenix Contact 5/5-ST-3, 5 GY7035, MC 1 Series Pluggable Terminal Block, 4-Contact, 5 mm Pitch, Through Hole, 1 Row

View all PCB Terminal Blocks

Subtotal (1 pack of 100 units)*

£393.60

(exc. VAT)

£472.30

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 06 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Pack*
100 +£3.936£393.60

*price indicative

RS Stock No.:
248-2386
Mfr. Part No.:
1779851
Brand:
Phoenix Contact
Find similar products by selecting one or more attributes.
Select all

Brand

Phoenix Contact

Product Type

Pluggable Terminal Block

Number of Contacts

4

Pitch

5mm

Current

12A

Number of Rows

1

Mount Type

Through Hole

Minimum Wire Size mm²

0.25mm²

Maximum Wire Size mm²

2.5mm²

Minimum Wire Size AWG

24 AWG

Maximum Wire Size AWG

12 AWG

Orientation

Straight

Wire Connection Method

Screw

Colour

Green

Voltage

320 V

Length

18.1mm

Series

5/5-ST-3, 5 GY7035, MC 1

Depth

15mm

Standards/Approvals

RoHS

Width

20 mm

COO (Country of Origin):
DE
The Phoenix Contact PCB connector has nominal cross section of 2.5 mm². It has nominal current 12 A and rated voltage (III/2) 320 V.

Pitch 5 mm

Number of positions 4

Drive form screw head slotted (L)

Screw thread M3

Locking without

Number of rows 1

Number of connections 4

Contact material Cu alloy

Surface characteristics hot-dip tin-plated

Housing Color green (6021)

Insulating material PA

Width 20 mm

Height 15 mm

Pitch 5 mm

Length 18.1 mm
