Phoenix Contact DMCC 0.5 Series Pluggable Terminal Block, 11-Contact, 2.54 mm Pitch, 2 Row, 1027613
- RS Stock No.:
- 228-6948
- Mfr. Part No.:
- 1027613
- Brand:
- Phoenix Contact
Subtotal (1 pack of 50 units)*
£61.25
(exc. VAT)
£73.50
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 13 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 50 + | £1.225 | £61.25 |
*price indicative
- RS Stock No.:
- 228-6948
- Mfr. Part No.:
- 1027613
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Product Type | Pluggable Terminal Block | |
| Number of Contacts | 11 | |
| Pitch | 2.54mm | |
| Number of Rows | 2 | |
| Current | 6A | |
| Minimum Wire Size mm² | 0.14mm² | |
| Housing Material | Polyamide | |
| Connector Gender | Female | |
| Maximum Wire Size mm² | 0.75mm² | |
| Minimum Wire Size AWG | 26AWG | |
| Maximum Wire Size AWG | 18AWG | |
| Orientation | Horizontal | |
| Wire Connection Method | Crimp | |
| Colour | Black | |
| Voltage | 160V | |
| Length | 16mm | |
| Standards/Approvals | No | |
| Series | DMCC 0.5 | |
| Width | 28.44mm | |
| Depth | 6.49mm | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Product Type Pluggable Terminal Block | ||
Number of Contacts 11 | ||
Pitch 2.54mm | ||
Number of Rows 2 | ||
Current 6A | ||
Minimum Wire Size mm² 0.14mm² | ||
Housing Material Polyamide | ||
Connector Gender Female | ||
Maximum Wire Size mm² 0.75mm² | ||
Minimum Wire Size AWG 26AWG | ||
Maximum Wire Size AWG 18AWG | ||
Orientation Horizontal | ||
Wire Connection Method Crimp | ||
Colour Black | ||
Voltage 160V | ||
Length 16mm | ||
Standards/Approvals No | ||
Series DMCC 0.5 | ||
Width 28.44mm | ||
Depth 6.49mm | ||
- COO (Country of Origin):
- CN
The Phoenix Contact printed-circuit board connector is cost-effective connection of crimped conductors in large quantities and it used gold-plated contacts ensure transfer quality remains stable over the long term. The contacts arranged in a double row enable high packing density in a compact area. This PCB connector has nominal cross section 0.75 mm² and its colour is black.
Ambient temperature (operation) -55 °C to 100 °C
Insulating material PA
Rated voltage (III/2) 160 V
