TE Connectivity Pluggable Terminal Block, 10-Contact, 3.5 mm Pitch, 1-Row

View all Pluggable Terminal Blocks

Subtotal (1 box of 200 units)*

£787.20

(exc. VAT)

£944.60

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 200 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Box*
200 +£3.936£787.20

*price indicative

RS Stock No.:
195-1937
Mfr. Part No.:
1-2350398-0
Brand:
TE Connectivity
Find similar products by selecting one or more attributes.
Select all

Brand

TE Connectivity

Number of Contacts

10

Product Type

Pluggable Terminal Block

Pitch

3.5mm

Number of Rows

1

Current

8A

Minimum Wire Size mm²

0.05mm²

Housing Material

Phosphor Bronze

Connector Gender

Male

Maximum Wire Size mm²

1.31mm²

Minimum Wire Size AWG

24 AWG

Maximum Wire Size AWG

16 AWG

Orientation

Vertical

Colour

Green

Wire Connection Method

Spring

Voltage

150 V

Width

7.7 mm

Length

35.7mm

Standards/Approvals

RoHS

Depth

14.3mm

Terminal blocks and strips are insulated connections that fasten two or more wires together and consist of an insulating frame and a clamping system. TE’s Terminal blocks and strips offer a reliable connection with a large variety of technologies and ranges to serve many industrial applications from control to power distribution.

TE Connectivity is expanding its Buchanan portfolio with Push-in clamp termination PCB Connectors to enable tool-less wire insertion of ferruled and unferruled wires. This saves up to 80% installation labor time vs. traditional screw-clamp termination, leading to important cost savings. The design of the PCB Connectors in 3.5 mm and 5.0 mm pitch consists of two-piece plug connectors with mating straight and right angle shrouded headers. TE engineers have designed this product range for use in control system applications to suit high density signal and power applications.
