Wurth Elektronik 3641 Series Pluggable Terminal Block, 12-Contact, 3.5 mm Pitch, 1-Row
- RS Stock No.:
- 191-6613
- Mfr. Part No.:
- 691364100012
- Brand:
- Wurth Elektronik
Bulk discount available
Subtotal (1 unit)*
£11.77
(exc. VAT)
£14.12
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 90 unit(s) shipping from 15 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £11.77 |
| 10 - 49 | £10.40 |
| 50 + | £9.50 |
*price indicative
- RS Stock No.:
- 191-6613
- Mfr. Part No.:
- 691364100012
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Number of Contacts | 12 | |
| Product Type | Pluggable Terminal Block | |
| Pitch | 3.5mm | |
| Number of Rows | 1 | |
| Current | 10A | |
| Minimum Wire Size mm² | 0.129mm² | |
| Housing Material | Polyamide | |
| Connector Gender | Male | |
| Maximum Wire Size mm² | 1.31mm² | |
| Minimum Wire Size AWG | 26 AWG | |
| Maximum Wire Size AWG | 16 AWG | |
| Orientation | Vertical | |
| Colour | Green | |
| Wire Connection Method | Solder | |
| Voltage | 1.6 kV | |
| Depth | 11.1mm | |
| Width | 15.8 mm | |
| Standards/Approvals | RoHS | |
| Series | 3641 | |
| Length | 52.4mm | |
| Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Number of Contacts 12 | ||
Product Type Pluggable Terminal Block | ||
Pitch 3.5mm | ||
Number of Rows 1 | ||
Current 10A | ||
Minimum Wire Size mm² 0.129mm² | ||
Housing Material Polyamide | ||
Connector Gender Male | ||
Maximum Wire Size mm² 1.31mm² | ||
Minimum Wire Size AWG 26 AWG | ||
Maximum Wire Size AWG 16 AWG | ||
Orientation Vertical | ||
Colour Green | ||
Wire Connection Method Solder | ||
Voltage 1.6 kV | ||
Depth 11.1mm | ||
Width 15.8 mm | ||
Standards/Approvals RoHS | ||
Series 3641 | ||
Length 52.4mm | ||
- COO (Country of Origin):
- CN
Wurth Elektronik WR-TBL are available in different connection types and offer large and modular Terminal Block possibilities in order to fulfil most of the requirements which can be found in the industrial marketplace.
