Wurth Elektronik 3.81mm Pitch 3 Way Vertical Pluggable Terminal Block, Header, PCB Mount, Solder Termination
- RS Stock No.:
- 191-5724
- Mfr. Part No.:
- 691701310003B
- Brand:
- Wurth Elektronik
5 In stock - FREE next working day delivery available
Price Each (On a Reel of 250)
£1.628
(exc. VAT)
£1.954
(inc. VAT)
Units | Per unit | Per Reel* |
|---|---|---|
| 250 - 250 | £1.628 | £407.00 |
| 500 + | £1.488 | £372.00 |
*price indicative
- RS Stock No.:
- 191-5724
- Mfr. Part No.:
- 691701310003B
- Brand:
- Wurth Elektronik
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
WR-TBL Würth Elektronik Teminal Blocks
The terminal block portfolio from Würth Elektronik gives piece of mind bringing power to the board. The newly stocked range covers wire protector, rising cage clamp, spring clamp and pluggable systems. From 2.50 mm up to 10.16 mm pitch, 57 Amp and a maximum number of up to 12 poles.
The terminal block portfolio from Würth Elektronik gives piece of mind bringing power to the board. The newly stocked range covers wire protector, rising cage clamp, spring clamp and pluggable systems. From 2.50 mm up to 10.16 mm pitch, 57 Amp and a maximum number of up to 12 poles.
Specifications
Attribute | Value |
|---|---|
| Pluggable Terminal Block Type | Header |
| Number of Contacts | 3 |
| Pitch | 3.81mm |
| Series | 7013B |
| Number of Rows | 1 |
| Body Orientation | Vertical |
| Mounting Type | PCB Mount |
| Termination Method | Solder |
| Current Rating | 10A |
| Voltage Rating | 2.5 kV ac, 300 V ac |
| Colour | Black |
| Material | Liquid Crystal Polymer |
