Phoenix Contact, 10.16mm Pitch, PC 6/..-STF, 6 Way, , Pluggable Terminal Block, Plug, Screw Mount, Screw Termination,
- RS Stock No.:
- 558-116
- Mfr. Part No.:
- 1913617
- Brand:
- Phoenix Contact
Subtotal (1 pack of 25 units)*
£1,300.79
(exc. VAT)
£1,560.95
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 01 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
---|---|---|
1 + | £1,300.79 | £52.032 |
*price indicative
- RS Stock No.:
- 558-116
- Mfr. Part No.:
- 1913617
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Phoenix Contact | |
Pluggable Terminal Block Type | Plug | |
Number of Contacts | 6 | |
Pitch | 10.16mm | |
Series | PC 6/..-STF | |
Number of Rows | 1 | |
Body Orientation | Straight | |
Mounting Type | Screw Mount | |
Termination Method | Screw | |
Select all | ||
---|---|---|
Brand Phoenix Contact | ||
Pluggable Terminal Block Type Plug | ||
Number of Contacts 6 | ||
Pitch 10.16mm | ||
Series PC 6/..-STF | ||
Number of Rows 1 | ||
Body Orientation Straight | ||
Mounting Type Screw Mount | ||
Termination Method Screw | ||
- COO (Country of Origin):
- PL
The Phoenix Contact PCB connector is engineered to provide a reliable and high-performance solution for electrical connections within circuit boards. Known for its robust construction and ease of use, this connector is designed with a nominal cross section of 6 mm² and accommodates a variety of conductive materials. With an exceptional current rating of 41 A, it ensures superior performance in demanding applications. The connector is crafted to operate under considerable voltage levels, making it ideal for industrial environments. Its innovative design features screw connections with tension sleeves, guaranteeing a secure and durable fit. Enhanced by integrated double steel springs, it offers added safety during fluctuations in temperature and power, making this connector a trusted choice in the field.
Designed for worldwide compatibility with a well-known connection principle
Ensures low temperature rise thanks to maximum contact force
Facilitates connection of multiple conductors seamlessly
Features an integrated protective guide to prevent incorrect conductor insertion
Offers superior mechanical stability with its screwable flange
Compliant with WEEE and RoHS for environmental safety
Constructed from high-quality materials for long-lasting durability
Suitable for use in a wide range of ambient temperatures, enhancing operational reliability
Ensures low temperature rise thanks to maximum contact force
Facilitates connection of multiple conductors seamlessly
Features an integrated protective guide to prevent incorrect conductor insertion
Offers superior mechanical stability with its screwable flange
Compliant with WEEE and RoHS for environmental safety
Constructed from high-quality materials for long-lasting durability
Suitable for use in a wide range of ambient temperatures, enhancing operational reliability
