Eaton XN Series Pluggable Terminal Block, 2-Contact, 140058 XN-2DI-120/230VAC
- RS Stock No.:
- 103-866
- Mfr. Part No.:
- 140058 XN-2DI-120/230VAC
- Brand:
- Eaton
Subtotal (1 unit)*
£51.33
(exc. VAT)
£61.60
(inc. VAT)
FREE delivery for orders over £50.00
Stocked by manufacturer
- Ready to ship from 18 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £51.33 |
*price indicative
- RS Stock No.:
- 103-866
- Mfr. Part No.:
- 140058 XN-2DI-120/230VAC
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Number of Contacts | 2 | |
| Product Type | Pluggable Terminal Block | |
| Current | 28A | |
| Orientation | Straight | |
| Wire Connection Method | Screw | |
| Voltage | 230 V | |
| Width | 12.6 mm | |
| Series | XN | |
| Standards/Approvals | UL Recognised, CSA-C22.2 No. 142, IEC/EN 61000-6-4, CE, CSA Class No.: 2252-01/2252-81, UL 508, IEC/EN 61131-2, IEC/EN 61000-6-2, cULus | |
| Depth | 55.4mm | |
| Length | 74.1mm | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Number of Contacts 2 | ||
Product Type Pluggable Terminal Block | ||
Current 28A | ||
Orientation Straight | ||
Wire Connection Method Screw | ||
Voltage 230 V | ||
Width 12.6 mm | ||
Series XN | ||
Standards/Approvals UL Recognised, CSA-C22.2 No. 142, IEC/EN 61000-6-4, CE, CSA Class No.: 2252-01/2252-81, UL 508, IEC/EN 61131-2, IEC/EN 61000-6-2, cULus | ||
Depth 55.4mm | ||
Length 74.1mm | ||
RoHS Status: Exempt
- COO (Country of Origin):
- DE
The Eaton digital input card operates with a universal power supply of 120/230VAC and With a compact design and screw or spring clamp connections, this input card is perfect for applications requiring 2 digital inputs. It offers a wide range of certifications, including CULus and CE, ensuring high-quality performance.
UL recognized
CE certified
IP20 protection rated
