Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 511-9200
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Colour | Red | |
| Length | 1.22m | |
| Material | Acetal | |
| Form | Rod | |
| Rod Diameter | 36mm | |
| Density | 1.41g/cm³ | |
| Tensile Strength | 55 MPa | |
| Flammability Rating | UL 94 HB | |
| Maximum Operating Temperature | +100°C | |
| Hardness | M 86 Rockwell | |
| Polymer Type | Copolymer | |
| Elongation | 30% | |
| Water Absorption | 0.5% | |
Select all | ||
|---|---|---|
Brand RS PRO | ||
Colour Red | ||
Length 1.22m | ||
Material Acetal | ||
Form Rod | ||
Rod Diameter 36mm | ||
Density 1.41g/cm³ | ||
Tensile Strength 55 MPa | ||
Flammability Rating UL 94 HB | ||
Maximum Operating Temperature +100°C | ||
Hardness M 86 Rockwell | ||
Polymer Type Copolymer | ||
Elongation 30% | ||
Water Absorption 0.5% | ||
Acetal, Copolymer (POM). POM Sheet : Polyoxymethylene
Has high strength and rigidity. The raw material granules used meet the requirements of FDA 21CFR 177.2470 for repeated food contact, this only applies to the colours the BLACK is NON-FDA compliant. The material is processed according to the granule suppliers guidelines. Applications: instrument handles, friction bearings/strips, insulators and seals etc.
Note
This material is not suitable or approved for medical implantation into the human body
Tolerance thickness plates: +0.2 mm → +0.9 mm
Tolerance thickness plates: +0.2 mm → +0.9 mm
These materials are available in both sheet and rod form. They possess good abrasion and chemical resistance, have good impact resistance and can be easily machined.
