OSI Optoelectronics Infrared Photodiode, 65 °, Through Hole TO-8
- RS Stock No.:
- 848-6275
- Mfr. Part No.:
- PIN DL-4
- Brand:
- OSI Optoelectronics
Subtotal (1 unit)*
£182.79
(exc. VAT)
£219.35
(inc. VAT)
FREE delivery for orders over £60.00
Last RS stock
- Final 3 unit(s), ready to ship
Units | Per unit |
|---|---|
| 1 + | £182.79 |
*price indicative
- RS Stock No.:
- 848-6275
- Mfr. Part No.:
- PIN DL-4
- Brand:
- OSI Optoelectronics
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | OSI Optoelectronics | |
| Spectrums Detected | Infrared | |
| Product Type | Photodiode | |
| Wavelength of Peak Sensitivity | 670nm | |
| Package Type | TO-8 | |
| Mount Type | Through Hole | |
| Packaging | Tape & Reel | |
| Number of Pins | 3 | |
| Minimum Wavelength Detected | 320nm | |
| Maximum Wavelength Detected | 1100nm | |
| Typical Fall Time | 0.08μs | |
| Amplified | No | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | 85°C | |
| Height | 5.59mm | |
| Width | 5mm | |
| Standards/Approvals | RoHS | |
| Length | 8mm | |
| Angle of Half Sensitivity | 65 ° | |
| Diameter | 15.24mm | |
| Automotive Standard | No | |
| Typical Rise Time | 0.08μs | |
| Dark Current | 0.2nA | |
| Breakdown Voltage | 30V | |
| Series | DL | |
| Polarity | Reverse | |
| Select all | ||
|---|---|---|
Brand OSI Optoelectronics | ||
Spectrums Detected Infrared | ||
Product Type Photodiode | ||
Wavelength of Peak Sensitivity 670nm | ||
Package Type TO-8 | ||
Mount Type Through Hole | ||
Packaging Tape & Reel | ||
Number of Pins 3 | ||
Minimum Wavelength Detected 320nm | ||
Maximum Wavelength Detected 1100nm | ||
Typical Fall Time 0.08μs | ||
Amplified No | ||
Minimum Operating Temperature -25°C | ||
Maximum Operating Temperature 85°C | ||
Height 5.59mm | ||
Width 5mm | ||
Standards/Approvals RoHS | ||
Length 8mm | ||
Angle of Half Sensitivity 65 ° | ||
Diameter 15.24mm | ||
Automotive Standard No | ||
Typical Rise Time 0.08μs | ||
Dark Current 0.2nA | ||
Breakdown Voltage 30V | ||
Series DL | ||
Polarity Reverse | ||
- COO (Country of Origin):
- US
OSI Position Sensing Detectors (PSDs)
This family of position sensing detectors (PSD), from OSI Optoelectronics, utilise duo-lateral technology. They provide a continuous analogue output which offer high position accuracy over the majority of the sensing area. One or two dimensional positions can be measured using this range of PSDs.
Suitable applications for these position sensing detectors (PSDs) include; beam alignment, position sensing, angle measurement, height measurements and motion analysis.
Features:
Super linear
High accuracy
Wide dynamic range
High reliability
Duo lateral structure
Photodiodes, OSI Optoelectronics
