Vishay VEMD3160FX01-GS08 Day Light PIN Photodiode, ±60 °, Surface PLCC 2
- RS Stock No.:
- 277-466
- Mfr. Part No.:
- VEMD3160FX01-GS08
- Brand:
- Vishay
Get a bulk buy discount
Add 200 more to save 4%
View bulk pricing optionsSubtotal (1 tape of 20 units)*
£7.04
(exc. VAT)
£8.44
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 7,440 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tape* | Saving |
|---|---|---|---|
| 20 - 180 | £0.352 | £7.04 | - |
| 200 - 480 | £0.335 | £6.70 | 4% |
| 500 - 980 | £0.31 | £6.20 | 11% |
| 1000 + | £0.285 | £5.70 | 19% |
*price indicative
- RS Stock No.:
- 277-466
- Mfr. Part No.:
- VEMD3160FX01-GS08
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Vishay | |
| Spectrums Detected | Day Light | |
| Product Type | PIN Photodiode | |
| Wavelength of Peak Sensitivity | 920nm | |
| Package Type | PLCC 2 | |
| Packaging | Tape & Reel | |
| Mount Type | Surface | |
| Number of Pins | 2 | |
| Minimum Wavelength Detected | 860nm | |
| Maximum Wavelength Detected | 1030nm | |
| Typical Fall Time | 180ns | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 110°C | |
| Length | 3.5mm | |
| Width | 2.8mm | |
| Height | 1.75mm | |
| Standards/Approvals | RoHS, AEC-Q101, MSL 3 | |
| Angle of Half Sensitivity | ±60 ° | |
| Series | VEMD | |
| Automotive Standard | AEC-Q101 | |
| Typical Rise Time | 180ns | |
| Breakdown Voltage | 20V | |
| Dark Current | 3nA | |
| Select all | ||
|---|---|---|
Brand Vishay | ||
Spectrums Detected Day Light | ||
Product Type PIN Photodiode | ||
Wavelength of Peak Sensitivity 920nm | ||
Package Type PLCC 2 | ||
Packaging Tape & Reel | ||
Mount Type Surface | ||
Number of Pins 2 | ||
Minimum Wavelength Detected 860nm | ||
Maximum Wavelength Detected 1030nm | ||
Typical Fall Time 180ns | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 110°C | ||
Length 3.5mm | ||
Width 2.8mm | ||
Height 1.75mm | ||
Standards/Approvals RoHS, AEC-Q101, MSL 3 | ||
Angle of Half Sensitivity ±60 ° | ||
Series VEMD | ||
Automotive Standard AEC-Q101 | ||
Typical Rise Time 180ns | ||
Breakdown Voltage 20V | ||
Dark Current 3nA | ||
The Vishay Silicon PIN Photodiode is a high speed, high sensitivity photodiode with a linear photo response, Ideal for applications like high speed photo detection, small signal detection, and proximity sensors.
Daylight blocking filter
AEC Q101 qualified
Excellent Ira linearity
Fast response times
