Phoenix Contact 5-ZB, LPT 6/4-7 Series PCB Terminal Block, 4-Contact, 7.5 mm Pitch, Wave Soldering Mount, 1 Row
- RS Stock No.:
- 269-7909
- Mfr. Part No.:
- 1098169
- Brand:
- Phoenix Contact
Subtotal (1 pack of 50 units)*
£279.75
(exc. VAT)
£335.70
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 50 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 50 + | £5.595 | £279.75 |
*price indicative
- RS Stock No.:
- 269-7909
- Mfr. Part No.:
- 1098169
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Product Type | PCB Terminal Block | |
| Number of Contacts | 4 | |
| Pitch | 7.5mm | |
| Current | 41A | |
| Number of Rows | 1 | |
| Mount Type | Wave Soldering Mount | |
| Housing Material | Polyamide | |
| Minimum Wire Size mm² | 0.2mm² | |
| Maximum Wire Size mm² | 6mm² | |
| Minimum Wire Size AWG | 8 AWG | |
| Maximum Wire Size AWG | 22 AWG | |
| Orientation | 0° | |
| Colour | Green | |
| Wire Connection Method | Push-in | |
| Voltage | 1000 V | |
| Standards/Approvals | DE1-66350, E60425-20210507 | |
| Series | 5-ZB, LPT 6/4-7 | |
| Depth | 27.85mm | |
| Length | 24.3mm | |
| Width | 31 mm | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Product Type PCB Terminal Block | ||
Number of Contacts 4 | ||
Pitch 7.5mm | ||
Current 41A | ||
Number of Rows 1 | ||
Mount Type Wave Soldering Mount | ||
Housing Material Polyamide | ||
Minimum Wire Size mm² 0.2mm² | ||
Maximum Wire Size mm² 6mm² | ||
Minimum Wire Size AWG 8 AWG | ||
Maximum Wire Size AWG 22 AWG | ||
Orientation 0° | ||
Colour Green | ||
Wire Connection Method Push-in | ||
Voltage 1000 V | ||
Standards/Approvals DE1-66350, E60425-20210507 | ||
Series 5-ZB, LPT 6/4-7 | ||
Depth 27.85mm | ||
Length 24.3mm | ||
Width 31 mm | ||
- COO (Country of Origin):
- CN
The Phoenix Contact PCB terminal block is rated for nominal current 41 A & rated voltage 1000 V at nominal cross section 6 mm2. The pin layout is Zigzag pinning W and connection direction 0°.
Green color
Tool free lever principle
Push in connection
Rated surge voltage (III/2) 8 kV
