Weidmuller LXXX Series PCB Terminal, 1-Contact, 15mm Pitch, PCB Mount, 1-Row, PCB Termination

This PCB terminal is designed for high-performance applications requiring robust power distribution. Measuring 31mm in depth and 16mm in width, it fits seamlessly onto printed circuit boards and delivers reliable connectivity even in demanding environments. With a 15mm pitch and a single row design, this terminal accommodates a maximum current rating of 150A and a voltage rating of 1000V.

• Designed for PCB mounting, simplifying circuit design
• Clamping range accommodates conductors from 0.5 to 50 mm²
• Durable black finish enhances visual integration on boards
• Integrates advanced clamping yoke technology for secure connections
• Compact design reduces complexity while enhancing usability

• Ideal for power electronics in industrial automation
• Used for connecting high-current systems in electrical panels
• Suitable for various mechanical requiring PCB connectivity
• Recommended for control systems for efficient energy transfer
• Used for custom PCB designs in electronic manufacturing

Its compact and simple design replaces the need for bolts or bus bars, streamlining the assembly process while providing reliable connections.

The clamping range allows connection of conductors from 0.5mm² to 50mm², accommodating a variety of wire sizes for diverse applications.

It operates effectively within temperatures ranging from -50 to 120 °C, making it suitable for various conditions in electrical installations.

It employs steel clamping-yoke technology to create secure, stable connections, optimising safety and performance in high-demand electrical setups.
