Phoenix Contact PTSM Series PCB Terminal Block, 6-Contact, 2.5 mm Pitch, Wave Soldering Mount, 1 Row
- RS Stock No.:
- 658-602
- Mfr. Part No.:
- 1814605
- Brand:
- Phoenix Contact
Subtotal (1 pack of 310 units)*
£751.64
(exc. VAT)
£901.97
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 06 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £751.64 | £2.425 |
*price indicative
- RS Stock No.:
- 658-602
- Mfr. Part No.:
- 1814605
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Number of Contacts | 6 | |
| Product Type | PCB Terminal Block | |
| Pitch | 2.5mm | |
| Current | 6A | |
| Number of Rows | 1 | |
| Mount Type | Wave Soldering Mount | |
| Housing Material | Polyamide | |
| Minimum Wire Size mm² | 0.14mm² | |
| Maximum Wire Size mm² | 0.5mm² | |
| Minimum Wire Size AWG | 26AWG | |
| Maximum Wire Size AWG | 20AWG | |
| Orientation | Vertical | |
| Colour | Signal White | |
| Wire Connection Method | Push-in Spring | |
| Voltage | 160V | |
| Series | PTSM | |
| Length | 5mm | |
| Width | 15.5mm | |
| Standards/Approvals | cULus Recognised, UL Recognised, VDE | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Number of Contacts 6 | ||
Product Type PCB Terminal Block | ||
Pitch 2.5mm | ||
Current 6A | ||
Number of Rows 1 | ||
Mount Type Wave Soldering Mount | ||
Housing Material Polyamide | ||
Minimum Wire Size mm² 0.14mm² | ||
Maximum Wire Size mm² 0.5mm² | ||
Minimum Wire Size AWG 26AWG | ||
Maximum Wire Size AWG 20AWG | ||
Orientation Vertical | ||
Colour Signal White | ||
Wire Connection Method Push-in Spring | ||
Voltage 160V | ||
Series PTSM | ||
Length 5mm | ||
Width 15.5mm | ||
Standards/Approvals cULus Recognised, UL Recognised, VDE | ||
- COO (Country of Origin):
- IN
The Phoenix Contact PCB terminal block that combines innovation with reliability. Ideal for various industrial applications, this terminal block supports a nominal current of 6 A and operates efficiently at a rated voltage of up to 160 V. Its design includes a robust push-in spring connection method, facilitating quick and secure wiring without the need for tools. Crafted for THR soldering or wave soldering, it ensures seamless integration into your PCB assembly process. The terminal block's signal white colour enhances visibility, while its compact dimensions make it a practical choice for space-constrained environments.
Compact dimensions allow for efficient use of space on PCBs
Stable colour ensures consistent appearance during welding and usage
High current carrying capacity of 6 A meets demanding application requirements
Vertical connection design supports multi row arrangements for optimal layout
