Phoenix Contact SPT Series PCB Terminal Block, 6-Contact, 5 mm Pitch, Surface, 1 Row
- RS Stock No.:
- 557-633
- Mfr. Part No.:
- 1824789
- Brand:
- Phoenix Contact
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
- RS Stock No.:
- 557-633
- Mfr. Part No.:
- 1824789
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Number of Contacts | 6 | |
| Product Type | PCB Terminal Block | |
| Pitch | 5mm | |
| Number of Rows | 1 | |
| Current | 17.5A | |
| Housing Material | Liquid Crystal Polymer | |
| Minimum Wire Size mm² | 0.2mm² | |
| Mount Type | Surface | |
| Maximum Wire Size mm² | 1.5mm² | |
| Minimum Wire Size AWG | 24AWG | |
| Maximum Wire Size AWG | 16AWG | |
| Orientation | 0° | |
| Colour | Black | |
| Wire Connection Method | Push-in | |
| Voltage | 32V | |
| Series | SPT | |
| Width | 29mm | |
| Standards/Approvals | VDE, cULus Recognised | |
| Depth | 7.7mm | |
| Length | 14.4mm | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Number of Contacts 6 | ||
Product Type PCB Terminal Block | ||
Pitch 5mm | ||
Number of Rows 1 | ||
Current 17.5A | ||
Housing Material Liquid Crystal Polymer | ||
Minimum Wire Size mm² 0.2mm² | ||
Mount Type Surface | ||
Maximum Wire Size mm² 1.5mm² | ||
Minimum Wire Size AWG 24AWG | ||
Maximum Wire Size AWG 16AWG | ||
Orientation 0° | ||
Colour Black | ||
Wire Connection Method Push-in | ||
Voltage 32V | ||
Series SPT | ||
Width 29mm | ||
Standards/Approvals VDE, cULus Recognised | ||
Depth 7.7mm | ||
Length 14.4mm | ||
- COO (Country of Origin):
- PL
The Phoenix Contact PCB terminal block is meticulously designed to enhance connectivity in printed circuit boards. This innovative product boasts a nominal current of 17.5 A and a rated voltage of 320 V, proving its reliability for diverse applications. Crafted for SMD soldering, it simplifies assembly while ensuring robust performance. With a distinctive push-in spring connection method, it delivers tool-free operation, making it effortlessly user-friendly. The terminal block caters to both rigid and flexible conductor connections, accommodating a variety of wire gauges. Additionally, its compact structure optimises space utilisation, making it an ideal choice for modern circuit designs.
Time-saving push-in connection eliminates the need for tools
Stable contact retention is ensured through defined contact force
Intuitive operation is facilitated with a colour-coded actuating push button
Designed for seamless integration into the SMT soldering process
Integrated test options enable quick and hassle-free testing
Allows for conductor connection from a single direction, streamlining device integration
Chemical compliance is guaranteed as it meets EU RoHS substance requirements
Manufactured with materials that resist electrical and mechanical strain
