Phoenix Contact SMSTB 2 Series PCB Connector, 9-Contact, 5.08 mm Pitch, 1 Row Screw

View all PCB Terminal Blocks

Subtotal (1 pack of 50 units)*

£542.42

(exc. VAT)

£650.90

(inc. VAT)

Add to Basket
Select or type quantity
Stock information currently inaccessible - Please check back later
Pack(s)
Per Pack
Per unit*
1 +£542.42£10.848

*price indicative

RS Stock No.:
497-096
Mfr. Part No.:
1826351
Brand:
Phoenix Contact
Find similar products by selecting one or more attributes.
Select all

Brand

Phoenix Contact

Product Type

PCB Connector

Number of Contacts

9

Pitch

5.08mm

Current

12A

Number of Rows

1

Housing Material

Polyamide

Connector Gender

Female

Termination Type

Screw

Colour

Green

Voltage

320V

Series

SMSTB 2

Width

45.72mm

Standards/Approvals

IEC 60999-1:1999-11, IEC 60512-13-2:2006-02, IEC 60068-2-70:1995-12, IEC 60512-13-5:2006-02, IEC 60512-1-1:2002-02, IEC 60512-1-2:2002-02, IEC 60068-2-6:2007-12, IEC 60512-9-1:2010-03, EN ISO 22479:2022-06, IEC 60512-5-1:2002-02, IEC 60512-3-1:2002-02, IEC 60664-1:2007-04, EN 60695-2-12, EN 60695-2-13, EN 60695-10-2, UL 94 V0, CSA Approval ID: 13631-2585951, cULus Recognised Approval ID: E60425-19931011, VDE Approval ID: 40050694

Depth

15.5mm

Length

25.6mm

COO (Country of Origin):
PL
The Phoenix Contact PCB connector is engineered to provide reliable, high-performance connections in tight installation settings. This connector is designed with an angled conductor connection that optimises space and allows for efficient installation. Capable of handling a nominal current of up to 12 A and featuring robust contact surfaces, it ensures minimal contact resistance and maximum durability. Furthermore, the connector's screw connection with a tension sleeve enhances secure conductor attachment, making it suitable for a variety of applications. With its low temperature rise and strong locking mechanism, this product exemplifies dependability in demanding environments.

Optimised for use in tight spaces, enhancing installation flexibility

Allows for easy access to conductor connections from one direction

Ensures maximum contact force, reducing temperature rise during operation

Features Sn-plated contacts for improved longevity and conductivity

Supports a wide range of conductor cross-sections for versatility

Complies with stringent environmental standards

Robust design guarantees reliable performance under load

Lightweight structure aids in simplifying overall system weight
