Phoenix Contact FK-MC Series PCB Terminal Block, 4-Contact, 2.5 mm Pitch, Push-in, 1 Row Screw

View all PCB Terminal Blocks

Subtotal (1 pack of 50 units)*

£115.32

(exc. VAT)

£138.38

(inc. VAT)

Add to Basket
Select or type quantity
Stocked by manufacturer
  • Ready to ship from 15 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s)
Per Pack
Per unit*
1 +£115.32£2.306

*price indicative

RS Stock No.:
492-791
Mfr. Part No.:
1768004
Brand:
Phoenix Contact
Find similar products by selecting one or more attributes.
Select all

Brand

Phoenix Contact

Number of Contacts

4

Product Type

PCB Terminal Block

Pitch

2.5mm

Number of Rows

1

Current

4A

Mount Type

Push-in

Housing Material

Polyamide

Termination Type

Screw

Colour

Black

Contact Gender

Female

Voltage

160V

Standards/Approvals

cULus Recognised Approval ID: E60425-19990913, VDE report with production monitoring Approval ID: 40013394, IEC 61984, IEC 60999-1:1999-11, IEC 60512-13-2:2006-02, IEC 60512-13-5:2006-02, IEC 60512-1-1:2002-02, IEC 60512-1-2:2002-02, IEC 60068-2-6:2007-12, IEC 60512-9-1:2010-03, ISO 6988:1985-02, IEC 60512-5-1:2002-02, IEC 60512-3-1:2002-02, IEC 60664-1:1992-10 + A1:2000-02 + A2:2002-05, DIN 46228‐1, JEDEC JESD 201, IEC 60068-2-82, IEC 60112, UL 94 V0, EN 60695-2-12, EN 60695-2-13, EN 60695-10-2

Width

10.6mm

Series

FK-MC

Length

19.05mm

Depth

11.75mm

COO (Country of Origin):
DE
The Phoenix Contact PCB connector has a nominal cross section of 0.5 mm² and is black in colour. It supports a nominal current of 4 A and a rated voltage (III/2) of 160 V. The connector features a Sn contact surface with a socket contact connection type. It includes 4 potentials, arranged in 1 row with 4 positions, providing secure and efficient electrical connections.

Defined contact force ensures that contact remains stable over the long term

Intuitive operation due to colour coded actuating push button

Operation and conductor connection from one direction enable integration into front of device

Quick and convenient testing using integrated test option
