WAGO 2616 Series PCB Connector, 5-Contact, 10 mm Pitch, Through Hole, 1 Row
- RS Stock No.:
- 225-429
- Mfr. Part No.:
- 2616-1105/020-000
- Brand:
- WAGO
Subtotal (1 box of 18 units)*
£223.98
(exc. VAT)
£268.78
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 16 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £223.98 | £12.443 |
*price indicative
- RS Stock No.:
- 225-429
- Mfr. Part No.:
- 2616-1105/020-000
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Product Type | PCB Connector | |
| Number of Contacts | 5 | |
| Pitch | 10mm | |
| Current | 76A | |
| Number of Rows | 1 | |
| Minimum Wire Size mm² | 0.75mm² | |
| Housing Material | Polyamide 66 | |
| Mount Type | Through Hole | |
| Maximum Wire Size mm² | 25mm² | |
| Minimum Wire Size AWG | 18AWG | |
| Maximum Wire Size AWG | 4AWG | |
| Wire Connection Method | Push-in | |
| Colour | Grey | |
| Voltage | 1000V | |
| Standards/Approvals | No | |
| Series | 2616 | |
| Depth | 32mm | |
| Width | 52.8mm | |
| Select all | ||
|---|---|---|
Brand WAGO | ||
Product Type PCB Connector | ||
Number of Contacts 5 | ||
Pitch 10mm | ||
Current 76A | ||
Number of Rows 1 | ||
Minimum Wire Size mm² 0.75mm² | ||
Housing Material Polyamide 66 | ||
Mount Type Through Hole | ||
Maximum Wire Size mm² 25mm² | ||
Minimum Wire Size AWG 18AWG | ||
Maximum Wire Size AWG 4AWG | ||
Wire Connection Method Push-in | ||
Colour Grey | ||
Voltage 1000V | ||
Standards/Approvals No | ||
Series 2616 | ||
Depth 32mm | ||
Width 52.8mm | ||
- COO (Country of Origin):
- PL
The Wago PCB terminal block is engineered for seamless connectivity in compact electronic applications. It features a unique Push-in CAGE CLAMP connection that allows for intuitive, tool-free operation, making it ideal for quick and reliable wire terminations. Designed with a five-pole configuration and a pin spacing of 10 mm, this terminal block ensures efficient and space-saving installation.
Supports solid and fine stranded conductors for flexible wiring options
Compatible with a range of ferrules and jumpers for enhanced utility
Meets strict international approvals for electrical and safety compliance
Compact dimensions facilitate easy installation in space constrained setups
Engineered for optimal conductor connection direction for user convenience
