WAGO 255 Series PCB Connector, 3-Contact, 7.62 mm Pitch, Through Hole, 1 Row
- RS Stock No.:
- 225-326
- Mfr. Part No.:
- 255-503/333-000
- Brand:
- WAGO
Subtotal (1 box of 45 units)*
£46.81
(exc. VAT)
£56.17
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 15 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £46.81 | £1.04 |
*price indicative
- RS Stock No.:
- 225-326
- Mfr. Part No.:
- 255-503/333-000
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Product Type | PCB Connector | |
| Number of Contacts | 3 | |
| Pitch | 7.62mm | |
| Current | 24A | |
| Number of Rows | 1 | |
| Mount Type | Through Hole | |
| Minimum Wire Size mm² | 0.08mm² | |
| Housing Material | Polyamide 66 | |
| Maximum Wire Size mm² | 2.5mm² | |
| Minimum Wire Size AWG | 28AWG | |
| Maximum Wire Size AWG | 12AWG | |
| Orientation | 90° | |
| Colour | Grey | |
| Voltage | 50V | |
| Depth | 23mm | |
| Series | 255 | |
| Width | 25.4mm | |
| Standards/Approvals | IEC/EN 60664-1, UL 1059, CSA | |
| Select all | ||
|---|---|---|
Brand WAGO | ||
Product Type PCB Connector | ||
Number of Contacts 3 | ||
Pitch 7.62mm | ||
Current 24A | ||
Number of Rows 1 | ||
Mount Type Through Hole | ||
Minimum Wire Size mm² 0.08mm² | ||
Housing Material Polyamide 66 | ||
Maximum Wire Size mm² 2.5mm² | ||
Minimum Wire Size AWG 28AWG | ||
Maximum Wire Size AWG 12AWG | ||
Orientation 90° | ||
Colour Grey | ||
Voltage 50V | ||
Depth 23mm | ||
Series 255 | ||
Width 25.4mm | ||
Standards/Approvals IEC/EN 60664-1, UL 1059, CSA | ||
- COO (Country of Origin):
- CH
The Wago PCB terminal block combines advanced design with practical functionality, ideal for applications where space and efficiency matter. Equipped with finger-operated levers, this terminal block ensures simplified in-field wiring while maintaining robust electrical connections. Its innovative CAGE CLAMP connection technology allows for quick and effortless conductor termination, facilitating smoother assembly processes.
Robust build accommodates a wide temperature range for reliable function
Ideal for quick assembly and maintenance in fast paced environments
Compliant with strict safety standards ensuring reliable performance
