WAGO 232 Series Right Angle PCB Mount PCB Header, 12-Contact, 1-Row, 7.5mm Pitch, Plug-In Termination
- RS Stock No.:
- 278-1625
- Mfr. Part No.:
- 232-842
- Brand:
- WAGO
Currently unavailable
Sorry, we don't know when this will be back in stock.
- RS Stock No.:
- 278-1625
- Mfr. Part No.:
- 232-842
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Number of Contacts | 12 | |
| Number of Rows | 1 | |
| Pitch | 7.5mm | |
| Type | Female Header | |
| Mounting Type | PCB Mount | |
| Body Orientation | Right Angle | |
| Termination Method | Plug-In | |
| Series | 232 | |
Select all | ||
|---|---|---|
Brand WAGO | ||
Number of Contacts 12 | ||
Number of Rows 1 | ||
Pitch 7.5mm | ||
Type Female Header | ||
Mounting Type PCB Mount | ||
Body Orientation Right Angle | ||
Termination Method Plug-In | ||
Series 232 | ||
- COO (Country of Origin):
- DE
The WAGO female header is horizontal or vertical PCB mounted via angled solder pins. It is for board to board and board to wire connections.
Easy to identify PCB inputs and outputs
RoHS compliant
RoHS compliant
