Samtec ARF6 Series Straight Surface PCB Socket, 8-Contact, 2 Row, 0.635 mm Pitch Solder
- RS Stock No.:
- 250-2804
- Mfr. Part No.:
- ARF6-08-S-D-A-K-TR-1
- Brand:
- Samtec
Subtotal (1 reel of 250 units)*
£1,074.75
(exc. VAT)
£1,289.75
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 26 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 250 + | £4.299 | £1,074.75 |
*price indicative
- RS Stock No.:
- 250-2804
- Mfr. Part No.:
- ARF6-08-S-D-A-K-TR-1
- Brand:
- Samtec
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Samtec | |
| Product Type | PCB Socket | |
| Number of Contacts | 8 | |
| Sub Type | PCB Socket | |
| Number of Rows | 2 | |
| Pitch | 0.635mm | |
| Housing Material | Thermoplastic | |
| Termination Type | Solder | |
| Mount Type | Surface | |
| Orientation | Straight | |
| Connector System | Wire-to-Board | |
| Series | ARF6 | |
| Minimum Operating Temperature | -20°C | |
| Row Pitch | 0.635mm | |
| Contact Gender | Male | |
| Contact Plating | Tin | |
| Contact Material | Copper | |
| Maximum Operating Temperature | 105°C | |
| Standards/Approvals | UL, RoHS | |
| Select all | ||
|---|---|---|
Brand Samtec | ||
Product Type PCB Socket | ||
Number of Contacts 8 | ||
Sub Type PCB Socket | ||
Number of Rows 2 | ||
Pitch 0.635mm | ||
Housing Material Thermoplastic | ||
Termination Type Solder | ||
Mount Type Surface | ||
Orientation Straight | ||
Connector System Wire-to-Board | ||
Series ARF6 | ||
Minimum Operating Temperature -20°C | ||
Row Pitch 0.635mm | ||
Contact Gender Male | ||
Contact Plating Tin | ||
Contact Material Copper | ||
Maximum Operating Temperature 105°C | ||
Standards/Approvals UL, RoHS | ||
RoHS Status: Exempt
The samtec Accelerate Slim Socket for ARC6 Series has 0.635 mm Pitch. It has rugged metal latching and shielding. It Supports 56 Gbps PAM4 (28 Gbps NRZ) applications.
Slimmest cable assembly in the industry is 76 mm width
High-density 2-row design
8, 16 and 24 differential pair configurations
34 AWG, 100 Ω Eye Speed® ultra low skew twinax cable
Multiple wiring options including reverse polarity
Mating board level socket (ARF6 Series) features standard rugged weld tabs for increased stability on the PCB
