Panasonic P4S Series Surface Mount PCB Socket, 20-Contact, 2-Row, 0.4mm Pitch, Solder Termination

RS Stock No.:: 179-0882
Mfr. Part No.:: AXT320124
Brand:: Panasonic

Panasonic P4S Series Surface Mount PCB Socket, 20-Contact, 2-Row, 0.4mm Pitch, Solder Termination

Available to back order for despatch 12/08/2024

Added

Price Each

£0.79

(exc. VAT)

£0.95

(inc. VAT)

Units	Per unit
1 - 24	£0.79
25 - 99	£0.75
100 - 249	£0.73
250 - 499	£0.71
500 +	£0.69

RS Stock No.:: 179-0882
Mfr. Part No.:: AXT320124
Brand:: Panasonic

Technical Reference

Datasheet

Legislation and Compliance

COO (Country of Origin):: JP

Product Details

FEATURES
“TOUGH CONTACT” construction for excellent vibration
resistance
Pattern wiring possible on PC board of the connector
undersurface
Models that support an ambient temperature of 125°C are
also available.
Connectors for inspection available
Shield type is also available.
APPLICATIONS
Mobile devices and industrial equipment

Specifications

Attribute	Value
Number of Contacts	20
Number of Rows	2
Pitch	0.4mm
Type	Socket
Mounting Type	Surface Mount
Termination Method	Solder
Current Rating	12A
Voltage Rating	60 V
Series	P4S
Contact Material	Copper
