Phoenix Contact COMBICON PC Series Right Angle Through Hole PCB Header, 4 Contact(s), 10.16 mm Pitch, 1 Row(s), Shrouded

View all PCB Headers

Subtotal (1 box of 50 units)*

£232.80

(exc. VAT)

£279.35

(inc. VAT)

Add to Basket
Select or type quantity
Stock information currently inaccessible
Units
Per unit
Per Box*
50 +£4.656£232.80

*price indicative

RS Stock No.:
859-7981
Mfr. Part No.:
1913662
Brand:
Phoenix Contact
Find similar products by selecting one or more attributes.
Select all

Brand

Phoenix Contact

Series

COMBICON PC

Product Type

PCB Header

Current

76A

Pitch

10.16mm

Housing Material

Polyamide

Number of Contacts

4

Number of Rows

1

Orientation

Right Angle

Shrouded/Unshrouded

Shrouded

Mount Type

Through Hole

Connector System

Wire-to-Board

Contact Plating

Silver

Contact Material

Silver

Row Pitch

10.16mm

Minimum Operating Temperature

-40°C

Termination Type

Solder

Contact Gender

Male

Tail Pin Length

4mm

Maximum Operating Temperature

100°C

Standards/Approvals

No

Voltage

1 kV

COO (Country of Origin):
DE
PCB headers, nominal cross section: 6 mm², color: green, nominal current: 76 A (41 A in combination with PC 6 plug), rated voltage (III/2): 1000 V, contact surface: Silver, type of contact: Male connector, Number of potentials: 4, Number of rows: 1, Number of positions per row: 4, number of connections: 4, product range: PC 6-16/..-G, pitch: 10.16 mm, mounting: Wave soldering, pin layout: Linear pinning, solder pin [P]: 5 mm, Stecksystem: POWER COMBICON 16, Locking: without, type of packaging: packed in cardboard, The nominal current of 76 A applies in connection with connectors from the PC 16 family. 41 A are reached in connection with PC 6 connectors (50 A in accordance with UL).
