3M 961 Series Straight Through Hole Pin Header, 36 Contact(s), 2.54mm Pitch, 1 Row(s), Unshrouded
- RS Stock No.:
- 827-7788
- Mfr. Part No.:
- 961136-6404-AR
- Brand:
- 3M
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
Alternative
This product is not currently available. Here is our alternative recommendation.
Each (In a Pack of 10)
£0.626
(exc. VAT)
£0.751
(inc. VAT)
- RS Stock No.:
- 827-7788
- Mfr. Part No.:
- 961136-6404-AR
- Brand:
- 3M
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | 3M | |
| Series | 961 | |
| Pitch | 2.54mm | |
| Number of Contacts | 36 | |
| Number of Rows | 1 | |
| Body Orientation | Straight | |
| Shrouded/Unshrouded | Unshrouded | |
| Mounting Type | Through Hole | |
| Connector System | Board to Board | |
| Termination Method | Solder | |
| Contact Material | Copper Alloy | |
| Contact Plating | Gold | |
| Current Rating | 2A | |
| Tail Pin Length | 3.3mm | |
| Mating Pin Length | 5.5mm | |
Select all | ||
|---|---|---|
Brand 3M | ||
Series 961 | ||
Pitch 2.54mm | ||
Number of Contacts 36 | ||
Number of Rows 1 | ||
Body Orientation Straight | ||
Shrouded/Unshrouded Unshrouded | ||
Mounting Type Through Hole | ||
Connector System Board to Board | ||
Termination Method Solder | ||
Contact Material Copper Alloy | ||
Contact Plating Gold | ||
Current Rating 2A | ||
Tail Pin Length 3.3mm | ||
Mating Pin Length 5.5mm | ||
- COO (Country of Origin):
- CN
961 Series Pin Strip Headers
The 961 Series of 3M™ Pin Stripe Headers will provide high reliability and durability. All models are end stackable
and will include solder stand-offs to facilitate production wave soldering.
All headers have an insulation material of High Temperature Thermoplastic and come with a
current rating of 2A
and will include solder stand-offs to facilitate production wave soldering.
All headers have an insulation material of High Temperature Thermoplastic and come with a
current rating of 2A
Straight and Right Angle Mounting Capabilities
Copper Alloy Contact
Single and dual row
2 Way to 40 Way
Copper Alloy Contact
Single and dual row
2 Way to 40 Way
Warning
Flammability: UL 94V-0
2.54mm 3M Range
