Samtec UMPS Series Straight Through Hole PCB Header, 3 Contact(s), 2.0mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 187-2174
- Mfr. Part No.:
- UMPS-03-05.5-G-VT-SM-WT-K
- Brand:
- Samtec
Available to back order for despatch when stock is available
Price Each
£1.17
(exc. VAT)
£1.40
(inc. VAT)
| Units | Per unit |
| 1 + | £1.17 |
- RS Stock No.:
- 187-2174
- Mfr. Part No.:
- UMPS-03-05.5-G-VT-SM-WT-K
- Brand:
- Samtec
Technical Reference
Legislation and Compliance
Product Details
Design flexibility as a two-piece system for power/signal applications
Up to 21 A per power blade
2 – 5 power blades on a 2.00 mm pitch
5 mm to 16 mm stack heights
Use with Samtec’s high-speed connector systems including: Edge Rate®, AcceleRate® HD, Q Strip®, Q2™, Q Rate®, LP Array™, SEARAY™, SEARAY™ 0.80 mm, Razor Beam™ LP, Tiger Eye™, Blade & Beam
Up to 21 A per power blade
2 – 5 power blades on a 2.00 mm pitch
5 mm to 16 mm stack heights
Use with Samtec’s high-speed connector systems including: Edge Rate®, AcceleRate® HD, Q Strip®, Q2™, Q Rate®, LP Array™, SEARAY™, SEARAY™ 0.80 mm, Razor Beam™ LP, Tiger Eye™, Blade & Beam
Specifications
Attribute | Value |
|---|---|
| Series | UMPS |
| Pitch | 2.0mm |
| Number of Contacts | 3 |
| Number of Rows | 1 |
| Body Orientation | Straight |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board to Board |
| Mounting Type | Through Hole |
| Termination Method | Solder |
| Contact Plating | Gold |
| Contact Material | Copper Alloy |
| Current Rating | 16.8A |
| Voltage Rating | 460.0 V , 650.0 V dc |
