JST JWPF Series Vertical PCB PCB Header, 4 Contact(s), 2 mm Pitch, 1 Row, Shrouded
- RS Stock No.:
- 177-4471
- Mfr. Part No.:
- B04B-JWPF-SK-R (LF)(SN)
- Brand:
- JST
Bulk discount available
Subtotal (1 box of 525 units)*
£632.10
(exc. VAT)
£758.625
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 14 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Box* |
|---|---|---|
| 525 - 2100 | £1.204 | £632.10 |
| 2625 - 4725 | £1.127 | £591.68 |
| 5250 + | £1.059 | £555.98 |
*price indicative
- RS Stock No.:
- 177-4471
- Mfr. Part No.:
- B04B-JWPF-SK-R (LF)(SN)
- Brand:
- JST
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | JST | |
| Series | JWPF | |
| Product Type | PCB Header | |
| Pitch | 2mm | |
| Current | 3A | |
| Number of Contacts | 4 | |
| Housing Material | Fibreglass Reinforced Polybutylene Terephthalate | |
| Number of Rows | 1 | |
| Orientation | Vertical | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | PCB | |
| Connector System | Wire-to-Board | |
| Contact Material | Copper Alloy | |
| Contact Plating | Tin | |
| Minimum Operating Temperature | -25°C | |
| Row Pitch | 2mm | |
| Termination Type | Crimp | |
| Tail Pin Length | 3.3mm | |
| Maximum Operating Temperature | 85°C | |
| Contact Gender | Male | |
| Standards/Approvals | No | |
| Voltage | 100 V | |
| Select all | ||
|---|---|---|
Brand JST | ||
Series JWPF | ||
Product Type PCB Header | ||
Pitch 2mm | ||
Current 3A | ||
Number of Contacts 4 | ||
Housing Material Fibreglass Reinforced Polybutylene Terephthalate | ||
Number of Rows 1 | ||
Orientation Vertical | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type PCB | ||
Connector System Wire-to-Board | ||
Contact Material Copper Alloy | ||
Contact Plating Tin | ||
Minimum Operating Temperature -25°C | ||
Row Pitch 2mm | ||
Termination Type Crimp | ||
Tail Pin Length 3.3mm | ||
Maximum Operating Temperature 85°C | ||
Contact Gender Male | ||
Standards/Approvals No | ||
Voltage 100 V | ||
- COO (Country of Origin):
- MY
JWPF connector can be used for the place of which especially waterproof is required this is wire to board connector that is grade 7 ingress protection of JIS C0920
Waterproof performance
Contained seal ring
Solid rubber seal
Double spring construction
Housing to Terminal locks
Inner housing lock
Header to use specifically with resin coated PC board
