Molex KK 508 Series Straight Through Hole Pin Header, 4 Contact(s), 5.08 mm Pitch, 1 Row(s), Unshrouded

View all PCB Headers

Subtotal (1 bag of 500 units)*

£185.00

(exc. VAT)

£220.00

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 3,000 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Bag*
500 +£0.37£185.00

*price indicative

RS Stock No.:
170-7132
Mfr. Part No.:
10-08-5041
Brand:
Molex
Find similar products by selecting one or more attributes.
Select all

Brand

Molex

Series

KK 508

Product Type

Pin Header

Current

7A

Pitch

5.08mm

Housing Material

Nylon

Number of Contacts

4

Number of Rows

1

Orientation

Straight

Shrouded/Unshrouded

Unshrouded

Mount Type

Through Hole

Connector System

Wire-to-Board

Contact Material

Brass

Contact Plating

Tin

Row Pitch

5.08mm

Termination Type

Solder

Minimum Operating Temperature

-40°C

Contact Gender

Male

Tail Pin Length

4.45mm

Maximum Operating Temperature

80°C

Standards/Approvals

No

Voltage

250 V

COO (Country of Origin):
CN

Polarizing Backwall Headers, 2599 Series


Mates with 3001and 5058 Series housings and 3002 Series PC Board connectors.

5.08mm Molex KK Range


This KK series interconnection system provides an economical and simple method of achieving wire to board and board to board connections. Particularly suited to applications where greater creepage and clearance distance are required, the 5.08mm pitch utilises the same crimp contacts, polarising pegs and tooling as the 3.96mm pitch.
