Samtec BBL Series Straight Through Hole Pin Header, 16 Contact(s), 2.54 mm Pitch, 1 Row(s), Unshrouded

View all PCB Headers
Bulk discount available

Subtotal (1 tube of 14 units)*

£31.542

(exc. VAT)

£37.856

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 15 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Tube*
14 - 126£2.253£31.54
140 - 686£2.145£30.03
700 - 1386£2.049£28.69
1400 - 6986£1.96£27.44
7000 +£1.917£26.84

*price indicative

RS Stock No.:
159-2943
Mfr. Part No.:
BBL-116-T-E
Brand:
Samtec
Find similar products by selecting one or more attributes.
Select all

Brand

Samtec

Series

BBL

Product Type

Pin Header

Pitch

2.54mm

Current

1A

Housing Material

Liquid Crystal Polymer

Number of Contacts

16

Number of Rows

1

Orientation

Straight

Shrouded/Unshrouded

Unshrouded

Mount Type

Through Hole

Connector System

Board-to-Board

Contact Material

Phosphor Bronze

Contact Plating

Tin

Row Pitch

2.54mm

Termination Type

Solder

Minimum Operating Temperature

-55°C

Contact Gender

Male

Maximum Operating Temperature

125°C

Tail Pin Length

3.18mm

Standards/Approvals

No

Mating Pin Length

2.67mm

.100" Low Profile Single Row, Screw Machine Terminal Strip

Application: Low profile single row to 32 positions

Contact System: Machined Terminal

Pitch: .100" (2.54 mm)
