Molex 70567 Series Vertical Through Hole PCB Header, 12 Contact(s), 2.54 mm Pitch, 2 Row(s), Shrouded
- RS Stock No.:
- 684-886
- Mfr. Part No.:
- 15-80-0125
- Brand:
- Molex
Subtotal (1 tube of 58 units)*
£233.54
(exc. VAT)
£280.25
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 11 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s) | Per Tube | Per unit* |
|---|---|---|
| 1 + | £233.54 | £4.027 |
*price indicative
- RS Stock No.:
- 684-886
- Mfr. Part No.:
- 15-80-0125
- Brand:
- Molex
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Molex | |
| Series | 70567 | |
| Product Type | PCB Header | |
| Pitch | 2.54mm | |
| Current | 2.5A | |
| Number of Contacts | 12 | |
| Housing Material | Thermoplastic | |
| Number of Rows | 2 | |
| Orientation | Vertical | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Through Hole | |
| Contact Material | Brass, Phosphor Bronze | |
| Contact Plating | Tin | |
| Row Pitch | 2.54mm | |
| Minimum Operating Temperature | -55°C | |
| Termination Type | Solder | |
| Maximum Operating Temperature | 105°C | |
| Tail Pin Length | 3.3mm | |
| Standards/Approvals | RoHS | |
| Voltage | 250 V | |
| Select all | ||
|---|---|---|
Brand Molex | ||
Series 70567 | ||
Product Type PCB Header | ||
Pitch 2.54mm | ||
Current 2.5A | ||
Number of Contacts 12 | ||
Housing Material Thermoplastic | ||
Number of Rows 2 | ||
Orientation Vertical | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Through Hole | ||
Contact Material Brass, Phosphor Bronze | ||
Contact Plating Tin | ||
Row Pitch 2.54mm | ||
Minimum Operating Temperature -55°C | ||
Termination Type Solder | ||
Maximum Operating Temperature 105°C | ||
Tail Pin Length 3.3mm | ||
Standards/Approvals RoHS | ||
Voltage 250 V | ||
- COO (Country of Origin):
- MY
The Molex C-Grid header is a highly versatile component designed for efficient signal and wire-to-board applications. This 2.54mm pitch C-Grid Header features a dual row, through-hole configuration and is optimized for high-temperature environments. With 12 circuits and advanced selective plating, it ensures a secure and reliable connection, making it ideal for various PCB applications. Built from durable materials, including high-temperature thermoplastic and brass, this header provides longevity and performance under demanding conditions. Its status as an active product and compliance with industry standards truly encapsulate its value within the PCB headers and receptacles category.
Polarized design secures proper mating and connection
Designed for ease of use with stackable features and vertical orientation
Compatible with a range of mating parts for versatile applications
Meets European RoHS compliance for assured environmental safety
