Molex 4455 Series Vertical PCB PCB Header, 3 Contact(s), 2.54 mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 684-444
- Mfr. Part No.:
- 22-18-2031
- Brand:
- Molex
Subtotal (1 tray of 500 units)*
£195.16
(exc. VAT)
£234.19
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 13 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tray(s) | Per Tray | Per unit* |
|---|---|---|
| 1 + | £195.16 | £0.39 |
*price indicative
- RS Stock No.:
- 684-444
- Mfr. Part No.:
- 22-18-2031
- Brand:
- Molex
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Molex | |
| Series | 4455 | |
| Product Type | PCB Header | |
| Current | 2.5A | |
| Pitch | 2.54mm | |
| Housing Material | Nylon | |
| Number of Contacts | 3 | |
| Number of Rows | 1 | |
| Orientation | Vertical | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | PCB | |
| Contact Plating | Gold | |
| Contact Material | Brass | |
| Row Pitch | 2.54mm | |
| Termination Type | Solder | |
| Tail Pin Length | 3.35mm | |
| Standards/Approvals | RoHS | |
| Voltage | 500 V | |
| Select all | ||
|---|---|---|
Brand Molex | ||
Series 4455 | ||
Product Type PCB Header | ||
Current 2.5A | ||
Pitch 2.54mm | ||
Housing Material Nylon | ||
Number of Contacts 3 | ||
Number of Rows 1 | ||
Orientation Vertical | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type PCB | ||
Contact Plating Gold | ||
Contact Material Brass | ||
Row Pitch 2.54mm | ||
Termination Type Solder | ||
Tail Pin Length 3.35mm | ||
Standards/Approvals RoHS | ||
Voltage 500 V | ||
- COO (Country of Origin):
- MY
The Molex KK 254 PC Board Connector is engineered to facilitate seamless board-to-board connections, presenting an ideal solution for signal transmission. This top-entry connector features a robust design with three circuits and is enhanced with gold plating for superior conductivity. Tailored specifically for PCB application, it strikes a perfect balance between functionality and reliability. With a compact vertical orientation and the inclusion of hooks, it ensures secure mating and dependable performance. Its compliance with industry standards makes it apt for diverse applications, ensuring it operates effectively even in challenging environments.
Designed for easy integration into PCB layouts with a vertical orientation
Equipped with a secure hooks mechanism for reliable connections
Featuring a natural resin colour for clear visual recognition
Constructed with low halogen materials, contributing to environmental sustainability
Compatible with a range of mating parts for versatile applications
Meets stringent compliance standards, including EU RoHS and REACH SVHC regulations
Offers simplified soldering processes with wave solder capability and specified temperature limits
Utilises a nylon resin for enhanced durability and thermal protection
Ideal for signal applications, ensuring optimal conductivity and minimal signal loss
