Molex 41662 Series Right Angle Through Hole PCB Header, 5 Contact(s), 3.96 mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 683-946
- Mfr. Part No.:
- 26-48-1052
- Brand:
- Molex
Subtotal (1 bag of 400 units)*
£198.33
(exc. VAT)
£238.00
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 06 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Bag(s) | Per Bag | Per unit* |
|---|---|---|
| 1 + | £198.33 | £0.496 |
*price indicative
- RS Stock No.:
- 683-946
- Mfr. Part No.:
- 26-48-1052
- Brand:
- Molex
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Molex | |
| Series | 41662 | |
| Product Type | PCB Header | |
| Current | 7A | |
| Pitch | 3.96mm | |
| Housing Material | Polyester | |
| Number of Contacts | 5 | |
| Number of Rows | 1 | |
| Orientation | Right Angle | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Through Hole | |
| Contact Material | Brass | |
| Contact Plating | Tin | |
| Termination Type | Solder | |
| Row Pitch | 3.96mm | |
| Tail Pin Length | 4.37mm | |
| Standards/Approvals | RoHS | |
| Voltage | 250 V | |
| Select all | ||
|---|---|---|
Brand Molex | ||
Series 41662 | ||
Product Type PCB Header | ||
Current 7A | ||
Pitch 3.96mm | ||
Housing Material Polyester | ||
Number of Contacts 5 | ||
Number of Rows 1 | ||
Orientation Right Angle | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Through Hole | ||
Contact Material Brass | ||
Contact Plating Tin | ||
Termination Type Solder | ||
Row Pitch 3.96mm | ||
Tail Pin Length 4.37mm | ||
Standards/Approvals RoHS | ||
Voltage 250 V | ||
- COO (Country of Origin):
- IN
The Molex KK 396 Breakaway Header designed for secure and reliable board-to-board and wire-to-board connections. This right-angle connector features five circuits with a robust tin plating, ensuring exceptional durability in demanding applications. With an active status within the PCB Headers and Receptacles category, this product not only meets essential industry standards but also provides an efficient solution for power and signal transmission. Engineered for versatility, the connector facilitates easy integration into various electronic devices, making it an ideal choice for manufacturers looking for quality and performance in their interconnect solutions.
Right angle design optimises space and mounting efficiency
Constructed with durable brass material for enhanced longevity
Through hole termination style assures stable PCB attachment
Polarised design prevents incorrect mating, ensuring safety
Meets rigorous compliance standards including EU RoHS
Partially shrouded for protection against dust and accidental contact
